Siemens SIMOCODE pro Function Manual

Tables, data records
3.3 Tables, PROFIBUS data records
SIMOCODE pro - Communication
Function Manual, 11/2018, A5E40508495002A/RS-AC/003
169
Byte.Bit
Designation
Information
DP
diagnostics *)
Error No. **)
19.0 Warnings - Level
monitoring
Warning - Warning I> IM UM W
19.1
Warning - Warning I<
IM UM
W
19.2
Warning - Warning P>
UM
W
19.3 Warning - Warning P< UM W
19.4
Warning - Warning cos phi<
UM
W
19.5
Warning - Warning U<
UM
W
19.6
Warning - Warning 0/4 - 20mA>
AM
W
19.7
Warning - Warning 0/4 - 20mA<
AM
W
20.0
Warning - Stalled rotor
IM UM
W
20.1
Reserved
20.3
Warning - No start permitted
BU0 BU1 BU2(+)
W
20.4
Warning - Number of starts >
BU0 BU1 BU2(+)
W
20.5 Warning - Just one start
possible
BU0 BU1 BU2(+) W
20.6 Warning - Motor operating
hours>
BU0 BU1 BU2(+) W
20.7
Warning - Motor stop time >
BU0 BU1 BU2(+)
W
21.0 Warnings -
Miscellaneous
Warning - ext. fault 1 BU0 BU1 BU2(+) W
21.1
Warning - ext. fault 2
BU0 BU1 BU2(+)
W
21.2
Warning - ext. fault 3
BU0 BU1 BU2(+)
W
21.3 Warning - ext. fault 4 BU0 BU1 BU2(+) W
21.4
Warning - ext. fault 5
BU2(+)
W
21.5 Warning - ext. fault 6 BU2(+) W
21.6
Reserved
21.7
Reserved
22.0 Warning - Analog module open
circuit
AM W
22.1 Warning - DM-F safety-related
tripping
DM-F W
22.2 Warning - DM-F test
requirement
DM-F W
22.3
Reserved
22.6
Warning - DM-F feedback circuit
DM-F
W
22.7
Warning - DM-FL simultaneity
DM-FL
W
23.0
Faults - General
Fault - HW fault basic unit
BU0 BU1 BU2(+)
F9
0
23.1 Fault - Module fault
(e.g. module IM, UM, DM)
BU0 BU1 BU2(+) F9 1
23.2 Fault - temporary components
(e.g. memory module)
BU0 BU1 BU2(+) F9 2
23.3
Fault - configuration error
BU0 BU1 BU2(+)
F16
3
23.4
Fault - Parameterization
BU0 BU1 BU2(+)
F16
4
