Siemens SIMOCODE pro Function Manual

Tables, data records
3.4 Tables, PROFINET data records
SIMOCODE pro - Communication
272 Function Manual, 11/2018, A5E40508495002A/RS-AC/003
3.4.2.16
Data record 139 - Marking
For external faults, limit monitors, and monitoring functions of the temperature and analog
modules, user-specific texts can be configured for marking.
You can access the following texts via data record 139:
● External fault 1 to 6 (status information, warnings, and faults)
● Limit 1 to 4 (status information)
● TM1 warnings T> / trip T> (status information, warnings, and faults)
● AM1 warning/tripping 0/4 - 20 mA<> (status information, warnings and faults).
Can be parameterized to have various meanings, e.g. fill level >, bearing hot, etc. To simplify
diagnostics, these texts can be saved in the device. These can be created, read out and
displayed, for example, with
SIMOCODE ES
. The texts do not contain any functions.
Note
Changing the marking
Each change to the marking requires that the communication interface be restarted when the
web server is active. A new start interrupts all Ethernet and PROFINET links and
reestablishes them afterward.
Table 3- 67 Data record 139 - Marking
Byte.Bit
Designation
Type
Information
0.0
Reserved
Byte[4]
4.0
Reserved
Byte[6]
10.0
Marking - External fault 1
Byte[10]
20.0
Marking - External fault 2
Byte[10]
30.0
Marking - External fault 3
Byte[10]
40.0
Marking - External fault 4
Byte[10]
50.0
Marking - External fault 5
Byte[10]
60.0
Marking - External fault 6
Byte[10]
70.0
Reserved
Byte[10]
80.0
Reserved
Byte[10]
90.0
Marking limit 1
Byte[10]
100.0
Marking limit 2
Byte[10]
110.0
Marking limit 3
Byte[10]
120.0
Marking limit 4
Byte[10]
130.0
Marking - TM warning T>
Byte[10]
140.0
Marking - TM trip T>
Byte[10]
150.0
Marking - Warning 0/4-20 mA>
Byte[10]
160.0 Marking - Warning 0/4-20 mA< Byte[10]
170.0
Marking - Trip 0/4-20 mA>
Byte[10]
180.0
Marking - Trip 0/4-20 mA<
Byte[10]
190.0
Reserved
Byte[10]
