Siemens SIMOCODE pro Function Manual

Tables, data records
3.4 Tables, PROFINET data records
SIMOCODE pro - Communication
248 Function Manual, 11/2018, A5E40508495002A/RS-AC/003
3.4.2.11
Data record 131 - Basic device parameters 2 (plug binary)
Table 3- 62 Data record 131 - Basic device parameters 2
Byte.Bit
Designation (PRM group)
Type
Range
Default
Note
Information
0.0
Reserved
Byte[4]
4.0
Byte parameters (40)
4.0
BU - Output 1
Byte
0 - 255
0
5.0 BU - Output 2 Byte 0 - 255 0
6.0
BU - Output 3
Byte
0 - 255
0
7.0
Reserved
Byte
0
8.0
OP - LED green 1
Byte
0 - 255
0
OP OPD
9.0
OP - LED green 2
Byte
0 - 255
0
OP OPD
10.0
OP - LED green 3
Byte
0 - 255
0
OP OPD
11.0
OP - LED green 4
Byte
0 - 255
0
OP OPD
12.0
OP - LED yellow 1
Byte
0 - 255
0
OP
13.0
OP - LED yellow 2
Byte
0 - 255
0
OP
14.0
OP - LED yellow 3
Byte
0 - 255
0
OP
15.0
Reserved
Byte
0
16.0
Cyclic send - Bit 0.0
Byte
0 - 255
105
Default: Status - ON<
17.0
Cyclic send - Bit 0.1
Byte
0 - 255
106
Default: Status - Off
18.0
Cyclic send - Bit 0.2
Byte
0 - 255
107
Default: Status - ON>
19.0 Cyclic send - Bit 0.3 Byte 0 - 255 128 Default: Event - Overload
operation
20.0 Cyclic send - Bit 0.4 Byte 0 - 255 110 Default: Status - Interlocking
time active
21.0
Cyclic send - Bit 0.5
Byte
0 - 255
120
Default: Status - Auto mode
22.0 Cyclic send - Bit 0.6 Byte 0 - 255 96 Default: Status - General
fault
23.0 Cyclic send - Bit 0.7 Byte 0 - 255 97 Default: Status - General
warning
24.0
OPC UA Send - Bit 1.0
Byte
0 - 255
0
25.0
OPC UA Send - Bit 1.1
Byte
0 - 255
0
26.0
OPC UA Send - Bit 1.2
Byte
0 - 255
0
27.0
OPC UA Send - Bit 1.3
Byte
0 .. 255
0
28.0
OPC UA Send - Bit 1.4
Byte
0 - 255
0
29.0
OPC UA Send - Bit 1.5
Byte
0 - 255
0
30.0
OPC UA Send - Bit 1.6
Byte
0 - 255
0
31.0
OPC UA Send - Bit 1.7
Byte
0 - 255
0
32.0
OPC UA Send - Bit 0.0
Byte
0 - 255
0
33.0
OPC UA Send - Bit 0.1
Byte
0 - 255
0
34.0
OPC UA Send - Bit 0.2
Byte
0 - 255
0
35.0
OPC UA Send - Bit 0.3
Byte
0 - 255
0
36.0
OPC UA Send - Bit 0.4
Byte
0 - 255
0
37.0
OPC UA Send - Bit 0.5
Byte
0 - 255
0
