Siemens SIMOCODE pro Function Manual

Tables, data records
3.4 Tables, PROFINET data records
SIMOCODE pro - Communication
202 Function Manual, 11/2018, A5E40508495002A/RS-AC/003
3.4
Tables, PROFINET data records
3.4.1
PROFINET tables
3.4.1.1
OPC UA variables
Node IDs
The name of the variable is composed of the namespace ID2 and the node ID as follows:
ns=http://siemens.com/automation/simocode/provpn;i=Node ID of the relevant variable.
Example:
You want to access the maximum motor current. You search for the node ID of the variable
"Max. Current I_max" in the following table: Node ID=33
Table 3- 45 Node IDs (1)
Node ID
Data type
Description
GG3
GG3 GP
Acyclic receive
11
Boolean
Acyclic receive - Bit 0.0
✓
✓
12
Boolean
Acyclic receive - Bit 0.1
✓
✓
13 Boolean Acyclic receive - Bit 0.2 ✓ ✓
14
Boolean
Acyclic receive - Bit 0.3
✓
✓
15
Boolean
Acyclic receive - Bit 0.4
✓
✓
16
Boolean
Acyclic receive - Bit 0.5
✓
✓
17
Boolean
Acyclic receive - Bit 0.6
✓
✓
18
Boolean
Acyclic receive - Bit 0.7
✓
✓
19
Boolean
Acyclic receive - Bit 1.0
✓
✓
20
Boolean
Acyclic receive - Bit 1.1
✓
✓
21
Boolean
Acyclic receive - Bit 1.2
✓
✓
22
Boolean
Acyclic receive - Bit 1.3
✓
✓
23
Boolean
Acyclic receive - Bit 1.4
✓
✓
24
Boolean
Acyclic receive - Bit 1.5
✓
✓
25
Boolean
Acyclic receive - Bit 1.6
✓
✓
26
Boolean
Acyclic receive - Bit 1.7
✓
✓
27
Unsigned word
Acyclic receive - analog value
✓
✓
Measured values
30
Unsigned byte
Thermal memory
✓
✓
31
Unsigned byte
Phase unbalance
✓
✓
32
Unsigned byte
Cos phi
✓
—
33 Unsigned word Max. current I_max ✓ ✓
34
Unsigned word
Current I_L1
✓
✓

Siemens SIMOCODE pro Specifications

General

Protection Class	IP20
Mounting Type	DIN rail mounting
Rated Operational Voltage	24 V DC
Rated Current	Up to 820 A
Protection Functions	Overload, short-circuit, phase failure, asymmetry, ground fault, motor stall
Operating Temperature Range	-25°C to +60°C
Communication Protocols	PROFIBUS DP, PROFINET, Modbus RTU
Analog Outputs	Up to 2
Temperature Monitoring	PTC/KTY, RTD (PT100/PT1000)
Digital Outputs	Relay outputs, Solid-state outputs
Analog Inputs	0/4-20mA, PT100/PT1000
