Siemens SIMOCODE pro Function Manual

Tables, data records
3.4 Tables, PROFINET data records
SIMOCODE pro - Communication
242 Function Manual, 11/2018, A5E40508495002A/RS-AC/003
3.4.2.10
Data record 130 - Basic device parameters 1
Table 3- 61 Data record 130 - Basic device parameters 1
Byte.
Bit
Designation (PRM group)
Type
Range
Unit
Default
Note
Information
0.0
Coordination (byte[4]
Byte
4.0 Device class Byte 5, 7, 9, 13 5 = BU1
7 = BU0
9 = BU2
13 = BU3
5.0
Thermistor (Th)
Bit
0, 1
1 = active; thermistor in the BU
5.1
Reserved
Bit[5]
5.6
Reserved
5.7
Initialization module (InM)
Bit
0, 1
6.0
Operator panel (OP)
Bit
0, 1
6.1
Analog module (AM1)
Bit
0, 1
6.2
Temperature module (TM1)
Bit
0, 1
6.3
Ground-fault module (EM)
Bit
0, 1
6.4
Digital module 1 (DM1)
Bit[2]
0 - 3
0 = no digital module
1 = monostable
2 = bistable
3 = DM-F (see Byte.Bit 3.4)
6.6 Digital module 2 (DM2) Bit[2] 0 - 2
7.0 Operator panel with display
(OPD)
Bit 0, 1
7.1 Ground-fault module for
3UL23 transformer (EM+)
Bit 0, 1
7.2
Analog module 2 (AM2)
Bit
0, 1
7.3
Temperature module 2 (TM2)
Bit
0, 1
7.4 DM1 - Special type Bit[2] 0, 1 0 = DM-FL
1 = DM-FP
7.6 Reserved
8.0 Current measuring (IM) Bit[7] 0 .. 5 IM / UM:
0 = no current measurement
1 = 0.3 A - 3 A
2 = 2.4 A - 25 A
3 = 10 A - 100 A
4 = 20 A - 200 A
5 = 63 A - 630 A
UM+:
9 = 0.3 A - 4 A
10 = 3 A - 40 A
11 = 10 A - 115 A
12 = 20 - 200 A
13 = 63 - 630 A
