Siemens SIMOCODE pro Function Manual

Tables, data records
3.4 Tables, PROFINET data records
SIMOCODE pro - Communication
222 Function Manual, 11/2018, A5E40508495002A/RS-AC/003
Table 3- 50 Socket assignment table - analog in float format
No.
Designation
Unit
Info
0
Not connected
1 Reserved
2
Reserved
3 Reserved
4
Current I_max_A_F
1 A
UM+
5
Current I_avg_A_F
1 A
UM+
6
Current I_L1_A_F
1 A
UM+
7
Current I_L2_A_F
1 A
UM+
8
Current I_L3_A_F
1 A
UM+
9
Active power P_F
1 W
UM+
10
Apparent power S_F
1 VA
UM+
11
Voltage UL1_F
1 V
UM+
12
Voltage UL2_F
1 V
UM+
13
Voltage UL3_F
1 V
UM+
14
Cos phi_F
1
UM+
15
Frequency_F
1 Hz
UM+
16
Reserved
...
Reserved
49
Reserved
50
Active power Pa_F
1)
1 W
V2.1 UM+
51 Active power Pb_F
1)
1 W V2.1 UM+
52
Reserved
...
Reserved
255
Reserved
1) When replacing the current/voltage acquisition module (UM+), you must check the sign
(+, -).
