Tables, data records
3.4 Tables, PROFINET data records
SIMOCODE pro - Communication
Function Manual, 11/2018, A5E40508495002A/RS-AC/003
221
No.
Designation
Unit
Information
86
Calculation module 1 - Output
87 Reserved
88
Reserved
89 Reserved
90
Calculation module 2 - Output
91
Analog arithmetic 1 output
92
Analog arithmetic 2 output
93
Analog multiplexer output
94
Reserved
..
Reserved
103
Reserved
104
Max. current I_max_10mA
10 mA
UM(+) IM
105
Current I_L1_10mA
10 mA
UM(+) IM
106
Current I_L2_10mA
10 mA
UM(+) IM
107
Current I_L3_10mA
10 mA
UM(+) IM
108
Max. current I_max_100mA
100 mA
UM(+) IM
109
Current I_L1_100mA
100 mA
UM(+) IM
110
Current I_L2_100mA
100 mA
UM(+) IM
111
Current I_L3_100mA
100 mA
UM(+) IM
112
Reserved
113 Reserved
114
Reserved
115
Reserved
116
TM2 - max. temperature
1 K
TM2
117
TM2 - temperature 1
1 K
TM2
118
TM2 - temperature 2
1 K
TM2
119 TM2 - temperature 3 1 K TM2
120
AM2 - input 1
AM2
121
AM2 - input 2
AM2
122
AM2 - input 3
AM2
123
Reserved
..
Reserved
255
Reserved
1) S7 format: 0/4mA=0; 20mA=27648
2) If "line-to-line voltage = 1," "Voltage U_Lx" contain the line-to-line voltages
