Siemens SIMOCODE pro Function Manual

Tables, data records
3.3 Tables, PROFIBUS data records
SIMOCODE pro - Communication
184 Function Manual, 11/2018, A5E40508495002A/RS-AC/003
Byte.Bit
Designation (PRM group)
Type
Range
Default
Note
Information
94.0
Truth table 3 3I/1O - input 1
Byte
0 - 255
0
BU0 BU1 BU2(+)
95.0 Truth table 3 3I/1O - input 2 Byte 0 - 255 0 BU0 BU1 BU2(+)
96.0
Truth table 3 3I/1O - input 3
Byte
0 - 255
0
BU0 BU1 BU2(+)
97.0 Reserved Byte 0
98.0
Timer 1 - input
Byte
0 - 255
0
BU0 BU1 BU2(+)
99.0
Timer 1 - reset
Byte
0 - 255
0
BU0 BU1 BU2(+)
100.0
Timer 2 - input
Byte
0 - 255
0
BU0 BU1 BU2(+)
101.0
Timer 2 - reset
Byte
0 - 255
0
BU0 BU1 BU2(+)
102.0
Counter 1 - input +
Byte
0 - 255
0
BU0 BU1 BU2(+)
103.0
Counter 1 - input -
Byte
0 - 255
0
BU0 BU1 BU2(+)
104.0
Counter 1 - reset
Byte
0 - 255
0
BU0 BU1 BU2(+)
105.0
Counter 2 - input +
Byte
0 - 255
0
BU0 BU1 BU2(+)
106.0
Counter 2 - input -
Byte
0 - 255
0
BU0 BU1 BU2(+)
107.0
Counter 2 - reset
Byte
0 - 255
0
BU0 BU1 BU2(+)
108.0
Signal conditioning 1 - input
Byte
0 - 255
0
BU0 BU1 BU2(+)
109.0
Signal conditioning 1 - reset
Byte
0 - 255
0
BU0 BU1 BU2(+)
110.0
Signal conditioning 2 - input
Byte
0 - 255
0
BU0 BU1 BU2(+)
111.0
Signal conditioning 2 - reset
Byte
0 - 255
0
BU0 BU1 BU2(+)
112.0
Non-volatile element 1 - ιnput
Byte
0 - 255
0
BU0 BU1 BU2(+)
113.0
Non-volatile element 1 - reset
Byte
0 - 255
0
BU0 BU1 BU2(+)
114.0 Non-volatile element 2 - input Byte 0 - 255 0 BU0 BU1 BU2(+)
115.0
Non-volatile element 2 - reset
Byte
0 - 255
0
BU0 BU1 BU2(+)
116.0
Flashing 1 - Input
Byte
0 - 255
0
BU0 BU1 BU2(+)
117.0
Flashing 2 - Input
Byte
0 - 255
0
BU0 BU1 BU2(+)
118.0
Flashing 3 - Input
Byte
0 - 255
0
BU0 BU1 BU2(+)
119.0
Flicker 1 - Input
Byte
0 - 255
0
BU0 BU1 BU2(+)
120.0 Flicker 2 - Input Byte 0 - 255 0 BU0 BU1 BU2(+)
121.0
Flicker 3 - Input
Byte
0 - 255
0
BU0 BU1 BU2(+)
122.0
Analog parameters (44)
122.0 PLC/PCS analog input Byte 0 - 255 16 Default: Max.
current I_max
BU0 BU1 BU2(+)
123.0
Reserved
Byte
0
