Siemens SIMOCODE pro Function Manual

Tables, data records
3.3 Tables, PROFIBUS data records
SIMOCODE pro - Communication
Function Manual, 11/2018, A5E40508495002A/RS-AC/003
183
Byte.Bit
Designation (PRM group)
Type
Range
Default
Note
Information
63.0 Control station - Operator
panel [OP] ON<
Byte 0 - 255 0
64.0 Control station - Operator panel
[OP] OFF
Byte 0 - 255 0
65.0 Control station - Operator panel
[OP] ON>
Byte 0 - 255 0
66.0 Control function - ON< Byte 0 - 255 73 Default: Group
control station
ON<
67.0 Control function - OFF Byte 0 - 255 74 Default: Group
control station
OFF
68.0 Control function - ON> Byte 0 - 255 75 Default: Group
control station
ON>
69.0 Control function - Feedback ON Byte 0 - 255 101
Default: Status
- current
flowing
70.0
External fault 1 - input
Byte
0 - 255
0
BU0 BU1 BU2(+)
71.0
External fault 2 - input
Byte
0 - 255
0
BU0 BU1 BU2(+)
72.0
External fault 3 - input
Byte
0 - 255
0
BU0 BU1 BU2(+)
73.0 External fault 4 - input Byte 0 - 255 0 BU0 BU1 BU2(+)
74.0
External fault 1 - Reset
Byte
0 - 255
0
BU0 BU1 BU2(+)
75.0
External fault 2 - Reset
Byte
0 - 255
0
BU0 BU1 BU2(+)
76.0
External fault 3 - Reset
Byte
0 - 255
0
BU0 BU1 BU2(+)
77.0
External fault 4 - Reset
Byte
0 - 255
0
BU0 BU1 BU2(+)
78.0
Cold starting (TPF)
Byte
0 - 255
0
BU0 BU1 BU2(+)
79.0 Test 1 - Input Byte 0 - 255 59 Default: Cyclic
receive - Bit
0.3
BU0 BU1 BU2(+)
80.0
Test 2 - Input
Byte
0 - 255
0
BU0 BU1 BU2(+)
81.0 Reset 1 - Input Byte 0 - 255 62 Default: Cyclic
receive - Bit
0.6
BU0 BU1 BU2(+)
82.0
Reset 2 - Input
Byte
0 - 255
0
BU0 BU1 BU2(+)
83.0
Reset 3 - Input
Byte
0 - 255
0
BU0 BU1 BU2(+)
84.0
Reserved
Byte
0
85.0
Reserved
Byte
0
86.0
Reserved
Byte
0
87.0
Reserved
Byte
0
88.0
Truth table 1 3I/1O - input 1
Byte
0 - 255
0
BU0 BU1 BU2(+)
89.0
Truth table 1 3I/1O - input 2
Byte
0 - 255
0
BU0 BU1 BU2(+)
90.0
Truth table 1 3I/1O - input 3
Byte
0 - 255
0
BU0 BU1 BU2(+)
91.0
Truth table 2 3I/1O - input 1
Byte
0 - 255
0
BU0 BU1 BU2(+)
92.0 Truth table 2 3I/1O - input 2 Byte 0 - 255 0 BU0 BU1 BU2(+)
93.0
Truth table 2 3I/1O - input 3
Byte
0 - 255
0
BU0 BU1 BU2(+)
