3.3 Tables, PROFIBUS data records
SIMOCODE pro - Communication
148 Function Manual, 11/2018, A5E40508495002A/RS-AC/003
No.
Designation
Designation
Information
201
Fault - Execution Time OFF
202 Fault - feedback (FB) ON
203
Fault - feedback (FB) OFF
204 Fault - Stalled positioner Positioner
205
Fault - Double 0
Solenoid valve / positioner
206
Fault - Double 1
Solenoid valve / positioner
207
Fault - End position
Solenoid valve / positioner
208
Fault - Antivalence
Positioner
209
Fault - Cold start (TPF) fault
BU0 BU1 BU2(+)
210
Fault - power failure (UVO)
BU2(+)
211
Fault - Operational Protection Off (OPO)
BU2(+)
212
Reserved
213
Reserved
214
Reserved
215
Reserved
216
Freely-programmable elements
Truth table 1 3I/1O output
BU0 BU1 BU2(+)
217
Truth table 2 3I/1O output
BU0 BU1 BU2(+)
218
Truth table 3 3I/1O output
BU0 BU1 BU2(+)
219
Truth table 4 3I/1O output
BU0 BU2(+)
220
Truth table 5 3I/1O output
BU2(+)
221 Truth table 6 3I/1O output BU2(+)
222
Truth table 7 2I/1O output
BU0 BU2(+)
223
Truth table 8 2I/1O output
BU0 BU2(+)
224
Truth table 9 5I/2O output 1
BU2(+)
225
Truth table 9 5I/2O output 2
BU2(+)
226
Reserved
227 Reserved
228
Reserved
229
Reserved
230
Reserved
231
Reserved
232
Timer 1 output
BU0 BU1 BU2(+)
233
Timer 2 output
BU0 BU1 BU2(+)
234
Timer 3 output
BU2(+)
235
Timer 4 output
BU2(+)
236
Counter 1 output
BU0 BU1 BU2(+)
237
Counter 2 output
BU0 BU1 BU2(+)
238
Counter 3 output
BU2(+)
339
Counter 4 output
BU2(+)
240
Signal conditioning 1 output
BU0 BU1 BU2(+)
241
Signal conditioning 2 output
BU0 BU1 BU2(+)
242
Signal conditioning 3 output
BU0 BU2(+)
