Siemens SIMOCODE pro Function Manual

Tables, data records
3.3 Tables, PROFIBUS data records
SIMOCODE pro - Communication
Function Manual, 11/2018, A5E40508495002A/RS-AC/003
155
Byte.Bit
Status message
Information
10.0
Warnings - Level monitoring
Warning - Warning I>
IM UM
10.1 Warning - Warning I< IM UM
10.2
Warning - Warning P>
UM
10.3 Warning - Warning P< UM
10.4
Warning - Warning cos phi<
UM
10.5
Warning - Warning U<
UM
10.6
Warning - warning 0/4 - 20 mA>
AM
10.7
Warning - warning 0/4 - 20 mA>
AM
11.0
Warning - Stalled rotor
IM UM
11.1
Reserved
11.3
Warning - No start permitted
BU0 BU1 BU2(+)
11.4
Warning - Number of starts >
BU0 BU1 BU2(+)
11.5
Warning - Just one start possible
BU0 BU1 BU2(+)
11.6
Warning - Motor operating hours>
BU0 BU1 BU2(+)
11.7
Warning - Motor stop time >
BU0 BU1 BU2(+)
12.0
Warnings - Miscellaneous
Warning - external fault 1
BU0 BU1 BU2(+)
12.1
Warning - external fault 2
BU0 BU1 BU2(+)
12.2
Warning - external fault 3
BU0 BU1 BU2(+)
12.3
Warning - external fault 4
BU0 BU1 BU2(+)
12.4
Warning - external fault 5
BU2(+)
12.5 Warning - external fault 6 BU2(+)
12.6
Reserved
12.7
Reserved
13.0
Warning - Analog module open circuit
BU2(+)
13.1
Warning - DM-F safety-related tripping
13.2
Warning - Test requirement
DM-FL DM-FP
13.3 Reserved
13.4
Reserved
13.5
Reserved
13.6
Warning - DM-F feedback circuit
DM-FL DM-FP
13.7
Warning - DM-FL
DM-FL
14.0
Reserved
14.1
Status information - Protection
Status - Emergency start executed
IM UM
14.2
Status - Cooling down period active
IM UM
14.3
Status - Pause time active
IM UM
14.4
Reserved
14.5
Reserved
14.6
Status information - Receive
Status - Cold starting (TPF)
BU0 BU1 BU2(+)
