Siemens SIMOCODE pro Function Manual

Tables, data records
3.3 Tables, PROFIBUS data records
SIMOCODE pro - Communication
188 Function Manual, 11/2018, A5E40508495002A/RS-AC/003
Byte.Bit
Designation (PRM group)
Type
Range
Unit
Default
Note
Information
21.6
Reserved
Bit[2]
0
22.0 External fault 5 - Response Bit[2] 1, 2, 3 1 0 = disabled
1 = signal
2 = warn
3 = tripping
BU2(+)
22.2 External fault 6 - Response Bit[2] 1, 2, 3 1 BU2(+)
22.4
Reserved
Bit[2]
0
22.6
Reserved
Bit[2]
0
23.0 Analog-value recording - Trigger
edge
Bit[2] 0, 1 0 0 = positive
1 = Negative
BU2(+)
23.2
Reserved
Bit[2]
0
23.4
Reserved
Bit[2]
0
23.6
Reserved
Bit[2]
0
24.0
Reserved
Bit[2]
0
24.2
Reserved
Bit[2]
0
24.4
Reserved
Bit[2]
0
24.6
Reserved
Bit[2]
0
25.0
Timer 3 - Type
Bit[2]
0, 1, 2, 3
0
0 = With closing
delay
1 = Closing delay
with memory
2 = With opening
delay
3 = With fleeting
closing
BU2(+)
25.2 Timer 4 - Type Bit[2] 0, 1, 2, 3 0 BU2(+)
25.4
Signal conditioning 3 - Type
Bit[2]
0, 1, 2, 3
0
0 = Non-inverting
1 = Inverting
2 = Edge rising
with memory
3 = Edge falling
with memory
BU0 BU2(+)
25.6
Signal conditioning 4 - Type
Bit[2]
0, 1, 2, 3
0
BU0 BU2(+)
26.0
Non-volatile element 3 - Type
Bit[2]
0, 1, 2, 3
0
BU2(+)
26.2 Non-volatile element 4 - Type Bit[2] 0, 1, 2, 3 0 BU2(+)
26.4 Calculation module 2 - Operator Bit[2] 0, 1, 2, 3 0 0 = +,
1 = -,
2 = *,
3 = /
BU2(+)
26.6
Reserved
Bit[2]
0
27.0
Reserved
Bit[2]
0
27.2
Reserved
Bit[2]
0
27.4 OPD - Operator panel display
(bit 0 to 1)
Bit[2] 0 - 4 2 0 = Manual
1 = 3 s
2 = 10 s
3 = 1 min
4 = 5 min
BU2+
27.6 OPD - Operator panel display
(bit 2 to 3)
Bit[2] 0 - 4 BU2+

Siemens SIMOCODE pro Specifications

General

Protection Class	IP20
Mounting Type	DIN rail mounting
Rated Operational Voltage	24 V DC
Rated Current	Up to 820 A
Protection Functions	Overload, short-circuit, phase failure, asymmetry, ground fault, motor stall
Operating Temperature Range	-25°C to +60°C
Communication Protocols	PROFIBUS DP, PROFINET, Modbus RTU
Analog Outputs	Up to 2
Temperature Monitoring	PTC/KTY, RTD (PT100/PT1000)
Digital Outputs	Relay outputs, Solid-state outputs
Analog Inputs	0/4-20mA, PT100/PT1000
