Siemens SIMOCODE pro Function Manual

Tables, data records
3.3 Tables, PROFIBUS data records
SIMOCODE pro - Communication
192 Function Manual, 11/2018, A5E40508495002A/RS-AC/003
Byte.Bit
Designation (PRM group)
Type
Range
Unit
Default
Note
Information
128.0
Truth Table 9 5I/2O type - Output 1
Bit[32]
0 ... 1..1B
0
BU2(+)
132.0 Truth Table 9 5I/2O type - Output 2 Bit[32] 0 ... 1..1B 0 BU2(+)
136.0 Calculation module 2, offset D-word -
0x800000000
x7FFFFFFF
0 BU2(+)
140.0 Calculation module 1, numerator /
offset
D-word 2x -
32768..32767
0 BU2(+)
1) Value range dependent on current range of the IM / UM and the conversion factor

Siemens SIMOCODE pro Specifications

General

Protection Class	IP20
Mounting Type	DIN rail mounting
Rated Operational Voltage	24 V DC
Rated Current	Up to 820 A
Protection Functions	Overload, short-circuit, phase failure, asymmetry, ground fault, motor stall
Operating Temperature Range	-25°C to +60°C
Communication Protocols	PROFIBUS DP, PROFINET, Modbus RTU
Analog Outputs	Up to 2
Temperature Monitoring	PTC/KTY, RTD (PT100/PT1000)
Digital Outputs	Relay outputs, Solid-state outputs
Analog Inputs	0/4-20mA, PT100/PT1000
