Siemens SIMOCODE pro Function Manual

Tables, data records
3.4 Tables, PROFINET data records
SIMOCODE pro - Communication
204 Function Manual, 11/2018, A5E40508495002A/RS-AC/003
Node ID
Data type
Description
GG3
GG3 GP
77
Unsigned word
Timer 2
✓
✓
78 Unsigned word Timer 3 ✓ ✓
79
Unsigned word
Timer 4
✓
✓
80 Unsigned word Counter 1 ✓ ✓
81
Unsigned word
Counter 2
✓
✓
82
Unsigned word
Counter 3
✓
✓
83
Unsigned word
Counter 4
✓
✓
84
Unsigned word
Calculation module 1 - output
✓
✓
85
Unsigned word
Calculation module 2 - output
✓
✓
86
Unsigned Dword
Motor operating hours
✓
✓
87
Unsigned Dword
Int. motor operating hours
✓
✓
88
Unsigned Dword
Device operating hours
✓
✓
89
Unsigned Dword
Number of starts
✓
✓
90
Unsigned Dword
Int. number of direct starts
✓
✓
91
Unsigned Dword
Int. number of reverse starts
✓
✓
92
Unsigned Dword
Consumed energy
✓
✓
93
Unsigned word
Timer 5
✓
✓
94
Unsigned word
Timer 6
✓
✓
95
Unsigned word
Counter 5
✓
✓
96
Unsigned word
Counter 6
✓
✓
97 Unsigned word Calculation module 3 - output ✓ ✓
98
Unsigned word
Calculation module 4 - output
✓
✓
99
Unsigned word
Analog multiplexer - output
✓
✓
100
Float
Consumed energy
✓
—
Diagnostic status
108
Boolean
Status - General fault
✓
✓
109 Boolean Status - General warning ✓ ✓
110
Boolean
Status - Device OK
✓
✓
111
Boolean
Status - Bus OK
✓
✓
112
Boolean
Status - PLC/DCS in run
✓
✓
113
Boolean
Status - Current flowing
✓
✓
114
Boolean
Status - PE command Start_Pause is pending
✓
✓
115
Boolean
Status - PE energy-saving mode active
✓
✓
116
Boolean
Status - On<<
✓
✓
117
Boolean
Status - On <
✓
✓
118
Boolean
Status - Off
✓
✓
119
Boolean
Status - On >
✓
✓
120
Boolean
Status - On >>
✓
✓
121
Boolean
Status - Start active
✓
✓
122
Boolean
Status - Interlocking time active
✓
✓
123
Boolean
Status - Change-over pause active
✓
✓
124
Boolean
Status - Positioner running in open direction
✓
—
