Siemens SIMOCODE pro Function Manual

Tables, data records
3.4 Tables, PROFINET data records
SIMOCODE pro - Communication
Function Manual, 11/2018, A5E40508495002A/RS-AC/003
237
Byte.Bit
Designation
Information
PNIO
diagnostic
status **)
PNIO error
number (channel
error type)
Error no.
37.0 Warnings - Level
monitoring
extended
Warning - Warning 0/4-20mA > AM2 2 0x104A
37.1 Warning - Warning 0/4-20mA < AM2 2 0x104B
37.2
Reserved bit[6]
38.0 Warnings -
Miscellaneous
extended
Warning - AM2 open circuit AM2 2 0x105C
38.1
Reserved bit[7]
39.0
Reserved bit[8]
40.0 Events -
Protection
extended
Event - TM2 warning T> TM2
40.1
Event - TM2 trip T>
TM2
40.2
Event - TM2 sensor fault
TM2
40.3
Event – TM2 out of range
TM2
40.4
Reserved bit[4]
41.0 Events - Level
monitoring
Event - Warning 0/4-20mA > AM2
41.1
Event - Warning 0/4-20mA <
AM2
41.2
Event - Trip 0/4-20mA > 2
AM2
41.3
Event - Trip 0/4-20mA <
AM2
41.4 Event - Limit 5 Limit monitor
5
41.5 Event - Limit 6 Limit monitor
6
41.6
Reserved bit[2]
42.0
Reserved bit[8]
43.0 Events -
Miscellaneous
extended
Event - AM2 open circuit AM2
43.1
Reserved bit[7]
44.0
Reserved Bit[16]
45.0
Reserved bit[8]
*) The "GEN. FAULT" LED on the basic unit is not activated; instead, the "SF" LED lights up
on the DM-FP (because PROFIsafe is not active)
**) PNIO diagnostic status for the raised alarm:
● 1 = Maintenance required
● 2 = Maintenance demanded
● 3 = Failure
***) No PNIO diagnostics
1) 3UF7510-1AA00-0 ground-fault module
