Siemens SIMOCODE pro Function Manual

Tables, data records
3.4 Tables, PROFINET data records
SIMOCODE pro - Communication
250 Function Manual, 11/2018, A5E40508495002A/RS-AC/003
Byte.Bit
Designation (PRM group)
Type
Range
Default
Note
Information
68.0 Control function - ON> Byte 0 - 255 75
Default: Group control station
ON>
69.0 Control function - Feedback ON Byte 0 - 255 101 Default: Status - Motor
current flowing
70.0
External fault 1 - Input
Byte
0 - 255
0
71.0
External fault 2 - Input
Byte
0 - 255
0
72.0
External fault 3 - Input
Byte
0 - 255
0
73.0
External fault 4 - Input
Byte
0 - 255
0
74.0
External fault 1 - Reset
Byte
0 - 255
0
75.0
External fault 2 - Reset
Byte
0 - 255
0
76.0
External fault 3 - Reset
Byte
0 - 255
0
77.0
External fault 4 - Reset
Byte
0 - 255
0
78.0
Cold start (TPF)
Byte
0 - 255
0
79.0 Test 1 - Input Byte 0 - 255 59 Default: Cyclic receive -
Bit 0.3
80.0
Test 2 - Input
Byte
0 - 255
0
81.0 Reset 1 - Input Byte 0 - 255 62 Default: Cyclic receive -
Bit 0.6
82.0
Reset 2 - Input
Byte
0 - 255
0
83.0
Reset 3 - Input
Byte
0 - 255
0
84.0
Reserved
Byte
0
85.0
Reserved
Byte
0
86.0 Reserved Byte 0
87.0
Reserved
Byte
0
88.0 Truth table 1 3I/1O - Input 1 Byte 0 - 255 0
89.0
Truth table 1 3I/1O - Input 2
Byte
0 - 255
0
90.0
Truth table 1 3I/1O - Input 3
Byte
0 - 255
0
91.0
Truth table 2 3I/1O - Input 1
Byte
0 - 255
0
92.0
Truth table 2 3I/1O - Input 2
Byte
0 - 255
0
93.0
Truth table 2 3I/1O - Input 3
Byte
0 - 255
0
94.0
Truth table 3 3I/1O - Input 1
Byte
0 - 255
0
95.0
Truth table 3 3I/1O - Input 2
Byte
0 - 255
0
96.0
Truth table 3 3I/1O - Input 3
Byte
0 - 255
0
97.0
Reserved
Byte
0
98.0
Timer 1 - Input
Byte
0 - 255
0
99.0
Timer 1 - Reset
Byte
0 - 255
0
100.0
Timer 2 - Input
Byte
0 - 255
0
101.0
Timer 2 - Reset
Byte
0 - 255
0
102.0
Counter 1 - Input +
Byte
0 - 255
0
103.0
Counter 1 - Input -
Byte
0 - 255
0
104.0
Counter 1 - Reset
Byte
0 - 255
0
105.0
Counter 2 - Input +
Byte
0 - 255
0
106.0
Counter 2 - Input -
Byte
0 - 255
0
