Siemens SIMOCODE pro Function Manual

Tables, data records
3.4 Tables, PROFINET data records
SIMOCODE pro - Communication
254 Function Manual, 11/2018, A5E40508495002A/RS-AC/003
Byte.Bit
Designation (PRM group)
Type
Range
Unit
Default
Note
Info
13.2
Monitoring limit 2
Bit[2]
0, 1, 2, 3
0
startup override)
13.4 Monitoring limit 3 Bit[2] 0, 1, 2, 3 0
13.6
Monitoring limit 4
Bit[2]
0, 1, 2, 3
0
14.0 Reserved Bit[2] 0
14.2
Reserved
Bit[2]
0
14.4
Reserved
Bit[2]
0
14.6 AM1 - active inputs Bit[2] 0, 1, 2 0 0 = 1 input
1 = 2 inputs
2 = 3 inputs
AM1
15.0
DM - Delays inputs
Bit[2]
0, 1, 2, 3
10 ms
1
Offset 6ms
DM1 DM2
15.2 AM1 - Response for open
circuit
Bit[2] 1, 2, 3 2 0 = Disabled
1 = Signaling
2 = Warn
3 = Tripping
AM1
15.4 EM - Response to external
ground fault
Bit[2] 1, 3 1 EM EM+
15.6 EM - response to warning of
an external ground fault
Bit[2] 0, 1, 2 0 EM EM+
16.0
Reserved
Bit[2]
0
16.2
Reserved
Bit[2]
0
16.4 DM-F - Test requirement
response
Bit[2] 0, 1, 2 0 0 = Disabled
1 = Signaling
2 = Warn
3 = Tripping
DM-F
16.6 DM-F - safety-related
tripping response
Bit[2] 0, 1, 2, 3 0 DM-F
17.0
TM1 - Trip response T>
Bit[2]
1, 3
3
TM1
17.2 TM1 - Warning response T> Bit[2] 0, 1, 2 2 TM1
17.4 TM1 - Response to a sensor
fault / out of range
Bit[2] 0, 1, 2, 3 2 TM1
17.6 TM1 - Active sensors Bit[2] 0, 1, 2 2 0 = 1 sensor
1 = 2 sensors
2 = 3 sensors
TM1
18.0
Trip response P>
Bit[2]
0, 1, 3
0
0 = Disabled
1 = Signaling
2 = Warn
3 = Tripping
UM(+)
18.2
Warning response P>
Bit[2]
0, 1, 2
0
UM(+)
18.4
Trip response P<
Bit[2]
0, 1, 3
0
UM(+)
18.6
Warning response P<
Bit[2]
0, 1, 2
0
UM(+)
19.0
Trip response cos phi <
Bit[2]
0, 1, 3
0
UM(+)
19.2
Warning response cos phi <
Bit[2]
0, 1, 2
0
UM(+)
19.4
Trip response U<
Bit[2]
0, 1, 3
0
UM(+)
19.6
Warning response U<
Bit[2]
0, 1, 2
0
UM(+)
20.0
Trip response 0/4-20 mA>
Bit[2]
0, 1, 3
0
AM1
20.2 Warning response 0/4-20
mA>
Bit[2] 0, 1, 2 0 AM1
20.4
Trip response 0/4-20 mA<
Bit[2]
0, 1, 3
0
AM1
20.6 Warning response 0/
4-20 mA<
Bit[2] 0, 1, 2 0 AM1
21.0 Reserved Bit[2] 0

Siemens SIMOCODE pro Specifications

General

Protection Class	IP20
Mounting Type	DIN rail mounting
Rated Operational Voltage	24 V DC
Rated Current	Up to 820 A
Protection Functions	Overload, short-circuit, phase failure, asymmetry, ground fault, motor stall
Operating Temperature Range	-25°C to +60°C
Communication Protocols	PROFIBUS DP, PROFINET, Modbus RTU
Analog Outputs	Up to 2
Temperature Monitoring	PTC/KTY, RTD (PT100/PT1000)
Digital Outputs	Relay outputs, Solid-state outputs
Analog Inputs	0/4-20mA, PT100/PT1000
