Siemens SIMOCODE pro Function Manual

Tables, data records
3.4 Tables, PROFINET data records
SIMOCODE pro - Communication
Function Manual, 11/2018, A5E40508495002A/RS-AC/003
261
Byte.Bit
Designation (PRM group)
Type
Range
Default
Note
Information
40.0
External fault 5 - Reset
Byte
0 - 255
0
41.0 External fault 6 - Reset Byte 0 - 255 0
42.0
Reserved
Byte
0
43.0 Reserved Byte 0
44.0
UVO fault
Byte
0 - 255
0
45.0
OPO error
Byte
0 - 255
0
46.0
Truth table 4 3I/1O - Input 1
Byte
0 - 255
0
47.0
Truth table 4 3I/1O - Input 2
Byte
0 - 255
0
48.0
Truth table 4 3I/1O - Input 3
Byte
0 - 255
0
49.0
Truth table 5 3I/1O - Input 1
Byte
0 - 255
0
50.0
Truth table 5 3I/1O - Input 2
Byte
0 - 255
0
51.0
Truth table 5 3I/1O - Input 3
Byte
0 - 255
0
52.0
Truth table 6 3I/1O - Input 1
Byte
0 - 255
0
53.0
Truth table 6 3I/1O - Input 2
Byte
0 - 255
0
54.0
Truth table 6 3I/1O - Input 3
Byte
0 - 255
0
55.0
Truth table 7 2I/1O - Input 1
Byte
0 - 255
0
56.0
Truth table 7 2I/1O - Input 2
Byte
0 - 255
0
57.0
Truth table 8 2I/1O - Input 1
Byte
0 - 255
0
58.0
Truth table 8 2I/1O - Input 2
Byte
0 - 255
0
59.0
Truth table 9 5I/2O - Input 1
Byte
0 - 255
0
60.0 Truth table 9 5I/2O - Input 2 Byte 0 - 255 0
61.0
Truth table 9 5I/2O - Input 3
Byte
0 - 255
0
62.0
Truth table 9 5I/2O - Input 4
Byte
0 - 255
0
63.0
Truth table 9 5I/2O - Input 5
Byte
0 - 255
0
64.0
Timer 3 - Input
Byte
0 - 255
0
65.0
Timer 3 - Reset
Byte
0 - 255
0
66.0 Timer 4 - Input Byte 0 - 255 0
67.0
Timer 4 - Reset
Byte
0 - 255
0
68.0
Counter 3 - Input +
Byte
0 - 255
0
69.0
Counter 3 - Input -
Byte
0 - 255
0
70.0
Counter 3 - Reset
Byte
0 - 255
0
71.0
Counter 4 - Input +
Byte
0 - 255
0
72.0
Counter 4 - Input -
Byte
0 - 255
0
73.0
Counter 4 - Reset
Byte
0 - 255
0
74.0
Signal conditioning 3 - Input
Byte
0 - 255
0
75.0
Signal conditioning 3 - Reset
Byte
0 - 255
0
76.0
Signal conditioning 4 - Input
Byte
0 - 255
0
77.0
Signal conditioning 4 - Reset
Byte
0 - 255
0
78.0
Non-volatile element 3 - Input
Byte
0 - 255
0
79.0
Non-volatile element 3 - Reset
Byte
0 - 255
0
80.0
Non-volatile element 4 - Input
Byte
0 - 255
0
81.0
Non-volatile element 4 - Reset
Byte
0 - 255
0
