Siemens SIMOCODE pro Function Manual

Tables, data records
3.5 Modbus data tables
SIMOCODE pro - Communication
Function Manual, 11/2018, A5E40508495002A/RS-AC/003
295
Input/holding register
Designation
Type
Range
Unit
Default
Comments
Info
Access
1)
Address
high/low
Bit
0x4187 high 0 Motor protection -
Type of load
Bit 0, 1 0 0 = 3-phase
1 = 1-phase
r
1 Motor protection -
Reset
Bit 0, 1 0 0 = Manual
1 = Auto
r
2 Reserved Bit 0 r
3 Save change-
over command
Bit 0, 1 0 r
4 Non-maintained
command mode
Bit 0, 1 0 r
5 Cold start level
(TPF)
Bit 0, 1 0 0 = NO contact
1 = NC contact
r
6 Type of
consumer load
Bit 0, 1 0 0 = Motor
1 = ohmic load
r
7
Reserved
Bit
0
r
low 0 External fault
level 1
Bit 0, 1 0 0 = NO contact
1 = NC contact
r
1 External fault
level 2
Bit 0, 1 0 r
2 External fault
level 3
Bit 0, 1 0 r
3 External fault
level 4
Bit 0, 1 0 r
4 Monitoring
external fault 1
Bit 0, 1 0 0 = Always
1 = Only motor ON
r
5 Monitoring
external fault 2
Bit 0, 1 0 r
6 Monitoring
external fault 3
Bit 0, 1 0 r
7 Monitoring
external fault 4
Bit 0, 1 0 r
Part - Bit[2]
parameter
0x4188 high 0-1 Thermistor -
Overload
response
Bit[2] 1, 2, 3 3 0 = Disabled
1 = Signaling
2 = Warn
3 = Tripping
r
2-3 Thermistor -
Response to
sensor fault
Bit[2] 0, 1, 2,
3
2 r
4-5 Internal ground
fault - Response
Bit[2] 0, 1, 2,
3
0 r
6-7 Motor protection -
Overload
response
Bit[2] 0, 1, 2,
3
0 r
low 0-1 Motor protection -
Overload
response
Bit[2] 0, 1, 2 2 r
