Siemens SIMOCODE pro Function Manual

Tables, data records
3.5 Modbus data tables
SIMOCODE pro - Communication
Function Manual, 11/2018, A5E40508495002A/RS-AC/003
309
Input/holding register
Designation
Type
Range
Unit
Default
Comments
Access
1)
Info
Address
high/
low
Bit
low Delay limit 2 Byte 0 ... 255 100
ms
5 r/w
0x439E high Delay limit 3 Byte 0 ... 255 100
ms
5 r/w
low Delay limit 3 Byte 0 ... 255 100
ms
5 r/w
0x439F
high
TM - Hysteresis
Byte
0 ... 255
1 K
5
r
low
Max. star time
Byte
0 ... 255
1 s
20
r
0x43A0 high UVO time Byte 0 ... 255 100
ms,
1 s,
10 s
0 r
low
Staggering time
Byte
0 ... 255
1 s
0
r
0x43A1
high
Trace - Pre-trigger
Byte
0 ... 20
5%
0
r
low Calculator 2 -
Denominator 1
Byte 0 ... 255 0 r
0x43A2 high Calculator 2 -
Numerator 2
Byte 0 ... 255 0 r
low Calculator 1 -
Denominator
Byte 0 ... 255 0 r
0x43A3 high Truth table 4
type 3I/1O
Byte 0 ... 111
11111B
0 r
low Truth table 5
type 3I/1O
Byte 0 ... 111
11111B
0 r
0x43A4 high Truth table 6
type 3I/1O
Byte 0 ... 111
11111B
0 r
low Calculator 2 -
Numerator 1
Byte -128 ...
127
0 r/w
0x43A5 high Calculator 2 -
Denominator 2
Byte -128 ...
127
0 r/w
low DM-F - Test
requirement level
Byte 0 ... 255 Week 0 r/w
Part - Word
parameters
r/w
0x43A6 AM1 - Start value
output
Word 0 ...
65535
0 Value for 0/4 mA r/w AM1
0x43A7 AM1 - End value
output
Word 0 ...
65535
27648 Value for 20 mA r/w AM1
0x43A8 TM1 - Trip level T> Word 0 ...
65535
1 K 0 r/w TM1
