Siemens SIMOCODE pro Function Manual

Communication
2.2 PROFINET communication
SIMOCODE pro - Communication
66 Function Manual, 11/2018, A5E40508495002A/RS-AC/003
Diagnostics for process faults
All SIMOCODE pro monitoring functions with "trip" configured as their response are
transmitted with the "fault" diagnostics status.
Diagnostics for device faults
Diagnostics events that can occur in connection with defective hardware or incorrect
parameterization are also transmitted with the "fault" diagnostics status.
The response of the different monitoring functions can be configured individually. Depending
on the function, the following can be selected by configuration:
● Deactivated: There is no response. No diagnostics are produced.
● Signaling: The diagnostics event is entered in data record 92 and is displayed in the
"Faults/Warnings/Events" online dialog box of SIMOCODE ES. No diagnostics alarm is
triggered.
● Warning: A diagnostics alarm is generated with the "maintenance demand" diagnostics
status.
● Tripping: A diagnostics alarm is generated with the "fault" diagnostics status.
Evaluating diagnostics with SIMATIC S7 300/400 and STEP 7 V5
Diagnostics with STEP 7 HW Config
In the online display of STEP 7 HW Config, after selection of the corresponding module
(in this case: SIMOCODE pro V PN), the status of the module is determined with the
"module status" function.
The following statuses are represented in the overview:
Table 2- 12 Module statuses in diagnostics with STEP 7 HW Config
Symbol representation
in HW Config Online
Status in HW Config Online
Possible cause with SIMOCODE
Module does not exist SIMOCODE shut down or not
accessible on the bus
Module defective Fault is pending
Maintenance required
Warning is pending
Maintenance required
Event it pending
OK
None
The detailed diagnostics is displayed as follows on the "IO device diagnostics" tab card
under "Channel-specific diagnostics":
Table 2- 13 Detailed diagnostics with STEP 7 HW Config
Slot
Channel No.
Error
1: I/O module
0
Error text, e.g. "Execution of ON command"

Siemens SIMOCODE pro Specifications

General

Protection Class	IP20
Mounting Type	DIN rail mounting
Rated Operational Voltage	24 V DC
Rated Current	Up to 820 A
Protection Functions	Overload, short-circuit, phase failure, asymmetry, ground fault, motor stall
Operating Temperature Range	-25°C to +60°C
Communication Protocols	PROFIBUS DP, PROFINET, Modbus RTU
Analog Outputs	Up to 2
Temperature Monitoring	PTC/KTY, RTD (PT100/PT1000)
Digital Outputs	Relay outputs, Solid-state outputs
Analog Inputs	0/4-20mA, PT100/PT1000
