Siemens SIMOCODE pro Function Manual

Communication
2.2 PROFINET communication
SIMOCODE pro - Communication
Function Manual, 11/2018, A5E40508495002A/RS-AC/003
71
Data block "API"
API (Application Process Identifier): SIMOCODE pro uses the standard API 0.
Data blocks "SlotNumber," "SubslotNumber"
As a compact PROFINET IO Device, SIMOCODE pro V PN (GP) has the following structure:
Table 2- 18 Data blocks "SlotNumber," "SubslotNumber"
Designation
SlotNumber
SubslotNumber
Head module
- Interface
- Port 1
- Port 2
0x0000 0x0001
0x8000
0x8001
0x8002
I/O module
0x0001
0x0001
PROFIsafe
1)
0x0002
0x0001
1) Only in conjunction with fail-safe DM-F PROFIsafe expansion module
Data block "ChannelNumber"
Table 2- 19 ChannelNumber
ChannelNumber
Meaning
0x0000 - 0x7FFF
Manufacturer-specific
0x8000
Submodule
Data block "ChannelProperties"
Table 2- 20 ChannelProperties
15
14
13
12
11
10
9
8
7
6
5
4
3
2
1
0
.Direction
.Specifier
.Qualifier
.Acc.
.Type
