Meaning RDY RUN/STOP OUT > 5V SF/BF:
Bus error
●
PROFIBUS master: At least 1 slave is missing
● PROFIBUS slave: No parameter assignment master available
● PROFINET: Failure of a connected I/O device; at least one of the
assigned I/O devices cannot be addressed; faulty or missing
configuration data.
Priority: 2
1)
x x x 2/1
(red)
Underlicensing of technology/option objects
Priority: 3
1)
x x x 0.5/1
(red)
Upgrade/downgrade operation running. 0.5/1
(yellow)
x x x
The upgrade/downgrade operation has completed
(power OFF/ON of the upgraded/downgraded devices is necessary)
2/1
(yellow)
x x x
Transition from STOP/STOPU to RUN x 2/1
(green)
x x
STOP/STOPU x 1
(yellow)
x x
RUN x 1
(green)
x x
Transition
●
from RUN to STOP/STOPU
● STOP to STOPU
● STOPU to STOP
x 2/1
(yellow)
x x
Memory reset requested by SIMOTION D410, or by means of mode
switch.
x 0.5/1
(yellow)
x x
Memory reset in progress x 0 x 0
Memory reset completed x 1
(yellow)
x x
Firmware download to the integrated PROFINET interface is busy 0 x x 2/1
(yellow)
Firmware download to the integrated PROFINET interface is completed
SIMOTION cannot enter the RUN and Online mode
x x x Λ
(red)
Upgrading SIMOTION devices (device update tool)
Upgrade/downgrade running x x x 0.5/1
(green)
Upgrade/downgrade completed with error x x x Λ
(red)
Upgrade/downgrade completed without error x x x 0
2)
Backing up diagnostic data and non-volatile data
Backing up diagnostic data and non-volatile data (backup running) x Λ
(yellow)
x x
Backing up diagnostic data and non-volatile data (backup completed) x Λ
(green)
x x
Diagnostics data
7.1 Diagnostics by means of LED displays
SIMOTION D410
Commissioning Manual, 04/2014 201
