data content. If the new file is successfully created, the backup copy of the backup file is
deleted.
NOTICE
Loss of data due to failure to make backup copies
Non-backed-up
non-volatile SIMOTION data can be lost on hardware replacement (module
defect), for example, if the current value of the retain variables have not been backed up and
replaced by their initial values again.
Back up the non-volatile SIMOTION data on the CF card.
NOTICE
Repeat referencing necessary after absolute encoder overflow
If
an absolute encoder overflow occurs after _savePersistentMemoryData, the actual position
value is no longer correct after the non-volatile SIMOTION data are restored.
In this case, homing (absolute encoder adjustment) must be repeated.
With the SCOUT functions "Save variables" and "Restore variables," you also have the option
of backing up to your PC and restoring data that were changed during operation and only
stored in the runtime system.
Reloading non‑volatile SIMOTION data
SIMOTION
data backed up on a CF card with _savePersistentMemoryData are restored in the
following cases:
1. after replacing a module, see Section Replacing modules (spare part scenario)
(Page 167).
2. after an memory reset, see Section Resetting the memory of SIMOTION D410 (Page 152).
3. by switch setting, see Section Deleting/restoring non-volatile SIMOTION data (Page 209).
To restore the data backed up via the service selector switch or web server, the existing backup
files PMEMORY.XML and PMEMORY.BAK in the "USER\SIMOTION" directory on the CF
card must be deleted. See also Section Deleting/restoring non-volatile SIMOTION data
(Page 209).
Commissioning (hardware)
3.5 User memory concept
SIMOTION D410
Commissioning Manual, 04/2014 47
