Table 4-29 ZSW1_TLS_PLC
Bit Signal name Remark
0 - -
1 motion_terminated_ska 0: Conditions for stopping the skew drive are not fulfilled
1: Motion terminated, skew drive
2 zero 0: Conditions for zero position are not fulfilled
1: Zero position reached
3 motion_terminated 0: Conditions for stopping the cylinders are not fulfilled
1: Cylinder motion terminated
4 skew_removed 0: Conditions for removing skew are not fulfilled
1: Skew oscillation eliminated
Amplitude of the oscillation is less than P301.
Note:
Noisy camera signals psi_cam also cause a certain level of noise in the model
angle psi_model. This can result in flickering of the status bit skew_removed. In
this case, the bit should be evaluated via an additional timer in the higher-level
control system.
5 - Reserved
6 - Reserved
7 - Reserved
8 a_out 0: Cylinder A is not extended
1: Cylinder A is extended
9 b_out 0: Cylinder B is not extended
1: Cylinder B is extended
10 c_out 0: Cylinder C is not extended
1: Cylinder C is extended
11 d_out 0: Cylinder D is not extended
1: Cylinder D is extended
12 a_in 0: Cylinder A is not retracted
1: Cylinder A is retracted
13 b_in 0: Cylinder B is not retracted
1: Cylinder B is retracted
14 c_in 0: Cylinder C is not retracted
1: Cylinder C is retracted
15 d_in 0: Cylinder D is not retracted
1: Cylinder D is retracted
Communication interface to SIMATIC S7
4.2 SIMOTION D for AddOn → SIMATIC S7
SC integrated STS, GSU
Operating Instructions, 07/2019, A5E48271265B AA 105
