Table 2-4 Overview of operating modes and required licenses
Operating modes and functions Basic License Advanced License
Manual mode (MAN) ✓ ✓
Manual mode (MAN) - soft approach ✓
Positioning (POS) ✓ ✓
Sway neutralization load position (SNL) ✓ ✓
Sway neutralization drive position (SND) ✓ ✓
Semi-automatic mode (SAM) ✓
Cylinder jogging ✓ ✓
Go to zero positions without skew damping ✓ ✓
TLS jogging without skew damping ✓ ✓
Go to zero positions with skew damping ✓
TLS jogging with skew damping ✓
TLS positioning ✓
Skew damping ✓
2.2.4 Product structure
The software package contains one AddOn DCC library, one AddOn FB library and two
application projects for STS and GSU cranes.
The DCC library comprises a collection of blocks that are implemented as DCC blocks. These
DCC blocks contain the complete Sway Control and TLS functionality. DCC is a representation
which supports graphic configuring and interconnection. You will find the detailed function
scope of the DCC library in Chapter AddOn DCC library (Page 37). The blocks are already
wired to each other and preconfigured in the application projects.
The FB library comprises a collection of blocks for the implementation of data exchange
between the higher-level control system and SIMOTION. These are implemented as function
blocks in "Structured Text" (ST).
The application projects contain a complete sequential control system for the specific crane
type (STS or GSU). The relevant configuration is implemented in the control system with the
AddOn for sway control.
2.3 Scope of supply
SIMOCRANE SC integrated STS, GSU contains:
● Software DVD
● Certificates for software licenses
System description
2.3 Scope of supply
SC integrated STS, GSU
22 Operating Instructions, 07/2019, A5E48271265B AA
