10.5.3 Error list AddOn
10.5.3.1 Overview
The errors from the sway control system are categorized as follows:
General and severe errors E0 to E19
Errors in the limit or prelimit switch area E20 to E29
Errors in semi-automatic mode E30 to E49
Other errors 1 E50 to E59
Other errors 2 E60 to E68
TLS errors E69 to E84
10.5.3.2 Brief description
The assignment of the error bits to the error messages in the output data are as follows:
Table 10-1 General and severe errors (error double word 1)
Error Bit No. Brief description
E0 - Cycle time too long
E1 13 Error in the DCC chart
E2 14 Copy protection damaged
E3 3 License error
E4 12 Camera measuring system faulted
E5 1 Invalid mode, trolley
E6 1 Invalid mode, hoist
E7 9 Invalid mode at the limit switch, trolley
E8 9 Invalid mode at the limit switch, hoist
E9 - Step change in hoisting height
E10 0 Invalid parameter file
E11 - Invalid parameter value
E12 - Language file error
E13-E19 - Reserved
- 20 Actual position over- or undershoots the limits of the set value range.
Note:
This error is not displayed in the SIMOCRANE CeCOMM diagnostic program and must be handled
by the higher-level control system.
Table 10-2 Errors in the limit or prelimit switch area
Error Bit No. Brief description
E20 - Forward prelimit switch switches incorrectly, trolley
E21 - Upper prelimit switch switches incorrectly, hoist
