4.2 SIMOTION D for AddOn → SIMATIC S7
4.2.1 Common
Table 4-19 SIMOTION → SIMATIC S7, Common
PZD Signal name Unit Format Remark
1 ZSW1_Common_PLC - WORD Status word
see below, Table "ZSW1_Common_PLC"
2 FAULT1 - DWORD Error message 1
from AddOn technology, see Chapter Error list AddOn
(Page 374)
3
4 FAULT2 - DWORD Error message 2
from AddOn technology, see Chapter Error list AddOn
(Page 374)
5
6 INFO_NO_AUTO_START - DWORD Information about SAM mode start
see below, Table "INFO_NO_AUTO_START"
7
8 PARSET_OUT 1...99 SINT Parameter set confirmation
Confirmation of the number of the active parameter set.
1: Parameter set 1
2: Parameter set 2
3: Parameter set 3
4: Parameter set 4
9 IMPNT mm DINT Current immersion point value
Either the internal or the external immersion point is
used as the current immersion point, depending on the
IMPNT_EXT_ACTIVE control bit.
The value is only meaningful when STS is selected.
10
11-12 - Reserved
