3.3.2.9 FB_TLSPLCToAddOn
Symbol (FBD representation)
)%B7/63/&7R$GG2Q
$55$<
7/6B,2B3,:EB&:
EB&:
U3RVB&\OB$
U3RVB&\OB%
U3RVB&\OB&
U3RVB&\OB'
L6B6NHZB([WHUQ
U6HW3RVB6NHZ$[LV
:25'
:25'
/5($/
/5($/
/5($/
/5($/
',17
/5($/
Figure 3-23 FB_TLSPLCToAddOn
Task
The "FB_TLSPLCToAddOn" block reads the input area from the PROFIBUS DP / PROFINET
PN for the DCC_SCTLS2 block and separates the array into words and bits.
Connections
The outputs must be connected using the unit-global variables of the "AddOn" MCC source file
with the inputs of the DCC_SCTLS2 DCC block.
Table 3-27 FB_TLSPLCToAddOn connections
Name Type Data
type
Unit-global variables of "AddOn" Meaning
TLS_IO_PIW IN Array
[0..15]
OF word
addon_tls_receive Input array
for the TLS2 block
b16_CW1 OUT WORD TLS_CW1 Control word 1
b16_CW2 OUT WORD TLS_CW2 Control word 2
r64Pos_Cyl_A OUT LREAL TLS_rpos_a Cylinder A position
r64Pos_Cyl _B OUT LREAL TLS_rpos_b Cylinder B position
r64Pos_Cyl _C OUT LREAL TLS_rpos_c Cylinder C position
r64Pos_Cyl _D OUT LREAL TLS_rpos_d Cylinder D position
i32S_Skew_Extern OUT DINT TLS_iskew_angle_ext External skew position for TLS
positioning
r64SetPos_SkewAxis OUT LREAL TLS_rskewpos_set Set position of electric skew
drive for external position
mode
