Short name Meaning Unit
S_REF delayed
[TR]
Position after the set delays mm
V_REF delayed
[TR]
Output velocity after the set delays mm/s
Table 8-3 Analog signals, hoist
Short name Meaning Unit
V_SET [HO] Hoist set velocity specified by the master switch mm/s
V_REF [HO] Hoist set velocity using the set ramps mm/s
V_POS [HO] Output velocity, hoist mm/s
V_ACT [HO] Current hoist velocity mm/s
S_REF [HO] Hoist set position mm
S_ACT [HO] Hoist actual position mm
S_REF delayed
[HO]
Position after the set delays mm
V_REF delayed
[HO]
Output velocity after the set delays mm/s
In the lower section of the diagram user interface, the states of the input and output bits in the
PLC are displayed in the distance/velocity-time curve with a legend on the right-hand side.
Individual parameters or all parameters can also be selected in this legend.
Variable recordings
In addition to the "Values to be transferred" signals, four signal traces with variable selection are
available on each tab of the dialog box. In this way, a scalar signal can usually be selected that
is then recorded for the trolley and hoist. The list of signals can be found in Appendix A5
(Page 437).
Zoom
You can zoom areas of the diagram to view a more detailed display. To do this, click and drag
the mouse pointer (from the top left to the bottom right - rectangular form) over the area of
interest. Resize the rectangle in the opposite direction (zoom out) to restore the original display.
The axes can be scrolled and zoomed.
It is also possible to use the zoom function for the detailed view during the recording. Press the
space bar to leave the zoom again and continue monitoring the recording.
The "Zoom In" and "Zoom Out" function is also active in the lower diagram area for displaying
the states of the bits.
