Connections
The inputs of the DCC block are connected via unit-global variables of the MCC source file
"AddOn" to the outputs of the "FB_HoistPLCToAddOn" block. The DCC block outputs are
interconnected with the inputs of the "FB_HoistAddOnToPLC" block using unit-global variables.
Table 3-7 DCC_SCHOIST connections
Name Type Data
type
Unit-global variables of "AddOn" Meaning
BRELEASE IN BOOL hoist_plc_release Release
BTRAVEL IN BOOL hoist_plc_travel TRAVEL control bit
BOM_POS IN BOOL hoist_plc_om_pos Positioning mode
BOM_SPEED IN BOOL hoist_plc_om_speed Manual mode (MAN)
BOM_HOIST_CONTROL IN BOOL hoist_plc_om_hoist_control Semi-automatic mode (SAM)
BLS_UP IN BOOL hoist_plc_ls_up Limit switch up
BLS_DN IN BOOL hoist_plc_ls_dn Limit switch down
BPRELS_UP IN BOOL hoist_plc_prels_up Prelimit switch up
BPRELS_DN IN BOOL hoist_plc_prels_dn Prelimit switch down
BBRAKE_CLOSED IN BOOL hoist_plc_brake_closed Output value enable
IOVERRIDE IN INT hoist_plc_override Override
RFIELD_WEAK IN REAL hoist_bt_field_weak Field weakening
RS_ACT_HO IN LREAL hoist_to_rs_act_ho Current hoist position
RS_SET_HO_EXTERN IN LREAL hoist_bt_s_set_ho_extern Target position
IS_OFFS_HO IN INT hoist_plc_offset Position offset
RV_ACT_HO IN LREAL hoist_to_rv_act_ho Current hoist velocity
RV_SET_HO IN LREAL hoist_bt_v_set_ho Set velocity
BREADY OUT BOOL hoist_sc_ready Release
BACTIVE OUT BOOL hoist_sc_active Active
BPOS_COMPLETED OUT BOOL hoist_sc_pos_completed Positioning
BTRAVEL_UP OUT BOOL hoist_sc_travel_up Lifting
BTRAVEL_DN OUT BOOL hoist_sc_travel_dn Lowering
BSTOP_AT_OBST_MAN_H
O
OUT BOOL hoist_sc_stop_at_obst_man Stopped before blocked region
(MAN only)
RV_POS_HO OUT LREAL hoist_to_rv_pos_ho Output velocity
RA_POS_HO OUT LREAL Output acceleration
IFINAL_TARG_HO OUT DINT adddata_1_hoist_final_target Final target position
BERROR OUT BOOL Error bit from the block
IERRORID OUT DINT Error number from the block
Error messages
If an error occurs, output "BERROR" is set and the error number is output at output
"IERRORID" (for a description and help, see Chapter Error list AddOn (Page 374)). If several
errors are present, the oldest error will be displayed.
Overview of the software
3.3 Sway control function blocks
SC integrated STS, GSU
Operating Instructions, 07/2019, A5E48271265B AA 39
