Brief description
The block is responsible for the internal administration of the target positions. Semi-automatic
mode (SAM) is possible without this block. In this case, the targets must be specified by the
crane control system.
Method of operation
This block provides the target generator functionality. More detailed information can be found
in Chapter Target generator (Page 195).
Proper functioning is dependent on use of the DCC_SCTROLLEY and DCC_SCHOIST AddOn
DCC blocks as well.
Connections
The inputs of the DCC block are connected via unit-global variables of the MCC source file
"AddOn" to the outputs of the "FB_TargetsPLCToAddOn" block. The DCC block outputs are
interconnected with the inputs of the "FB_TargetsAddOnToPLC" block using unit-global
variables.
Table 3-9 DCC_SCTARGETS connections
Name Type Data
type
Unit-global variables of "AddOn" Meaning
BUSE_LASH_PLATF IN BOOL targets_plc_use_lash_plat Use lashing platform
BSTACK_FORM_BIT0 IN BOOL targets_plc_stack_form_bit0 Control bit 0
BSTACK_FORM_BIT1 IN BOOL targets_plc_stack_form_bit1 Control bit 1
ILANE_SHIP_LOAD IN SINT targets_plc_lane_ship_load Load lane to the ship
ILANE_SHIP_UNLOAD IN SINT targets_plc_lane_ship_unload Unload lane to the ship
BNO_SHIP_LOAD IN BOOL - No further loading of the ship
BNO_SHIP_UNLOAD IN BOOL - No further unloading of the ship
BCYCLING IN BOOL targets_plc_cycling Function is not enabled
BOFFSET_TO_LAND IN BOOL targets_plc_offset_to_land Target offset in the land direction
BOFFSET_TO_WATER IN BOOL targets_plc_offset_to_water Target offset in the water direction
BLEARN_LASH_PLATF IN BOOL targets_plc_learn_lash_platf Learn current position as lashing
platform
BLEARN_PARK_POS IN BOOL targets_plc_learn_park_pos Learn current position as parking
position
ILEARN_POS_LANE IN SINT targets_plc_learn_pos_lane Assign current position to a truck
lane
BUSE_EXTERN_TARGETS IN BOOL targets_plc_use_extern_targets Use target position from PLC
BINIT_TARGETS IN BOOL targets_plc_init_targets INIT_TARGET
BDIRECTION_LAND OUT BOOL targets_sc_direction_land Target lies in the land direction
BDIRECTION_WATER OUT BOOL targets_sc_direction_water Target lies in the water direction
ITARGET_TROLLEY OUT DINT - Target coordinates for trolley
ITARGET_HOIST OUT DINT - Target coordinates for the hoist
ILANE_LOAD_OK OUT SINT targets_sc_lane_load_ok Load lane to the ship
Overview of the software
3.3 Sway control function blocks
SC integrated STS, GSU
Operating Instructions, 07/2019, A5E48271265B AA 43
