Connections
The inputs of the DCC block are connected via unit-global variables of the MCC source file
"AddOn" to the outputs of the "FB_IntpoPLCToAddOn" block. The DCC block outputs are
interconnected with the inputs of the "FB_IntpoAddOnToPLC" block using unit-global variables.
Table 3-16 DCC_SCINTPO connections
Name Type Data type Unit-global variables of "AddOn" Meaning
BENABLE IN BOOL intpo_PLC_Enable Transfer Activate transfer of interpolation points
BLIST_IDX IN BYTE intpo_PLC__Index_Rcv Received interpolation point number
BCOUNT OUT BYTE intpo_SC_Count Number of interpolation points
BCURR_IDX OUT BYTE intpo_SC_Index_Snd Sent interpolation point number
IPOS_TR OUT DINT intpo_SC_HO_Pos Hoist position (corresponding to received
interpolation point number)
IPOS_HO OUT DINT intpo_SC_TR_Pos Trolley position (corresponding to re‐
ceived interpolation point number)
BERROR OUT BOOL intpo_SC_Error Invalid interpolation point number
Error messages
If the specified interpolation point number is larger than the current number, the BERROR
output is set.
