OUTPUT_FIL_1_DAMP [n] 0...7 index of the parameter set
Cross reference: -
Damping of control output filter 1 Related to:
HLA
Protection level:
3/3
Unit:
-
Default:
1.0
Minimum:
0.05
Maximum:
1.0
Data type:
FLOAT
Active:
Immediately
Enter damping for control output filter 1 (PT2 low-pass).
5288
OUTPUT_FIL_1_SUP_FREQ [n] 0...7 index of the parameter set
Cross reference: -
Blocking frequency of control output filter 1 Related to:
HLA
Protection level:
3/3
Unit:
Hz
Default:
3500.0
Minimum:
1.0
Maximum:
7999.0
Data type:
FLOAT
Active:
Immediately
Enter blocking frequency for control output filter 1 (bandstop)
5289
OUTPUT_FIL_1_BW [n] 0...7 index of the parameter set
Cross reference: -
Bandwidth of control output filter 1 Related to:
HLA
Protection level:
3/3
Unit:
Hz
Default:
500.0
Minimum:
5.0
Maximum:
7999.0
Data type:
FLOAT
Active:
Immediately
Enter -3dB bandwidth for control output filter 1 (bandstop).
5290
OUTPUT_FIL_1_BW_NUM [n] 0...7 index of the parameter set
Cross reference: -
Numerator bandwidth for control output filter 1 Related to:
HLA
Protection level:
3/3
Unit:
Hz
Default:
0.0
Minimum:
0.0
Maximum:
7999.0
Data type:
FLOAT
Active:
Immediately
Enter the numerator bandwidth for control output filter 1 (damped bandstop).
Entering a value of 0 initializes the filter as an unattenuated bandstop filter. The
value set in MD 5290 must not exceed twice the value set in MD 5289.
