10.03
4.5 Manipulated voltage output
4-130
Siemens AG, 2003. All rights reserved
SINUMERIK 840D/SIMODRIVE 611 digital, HLA Module (FBHLA) - 10.03 Edition
4.5.2 Control output filter
5280
NUM_OUTPUT_FILTERS [n] 0...7 index of the parameter set
Cross reference: -
Number of control output filters Related to:
HLA
Protection level:
3/3
Unit:
-
Default:
0
Minimum:
0
Maximum:
1
Data type:
UNS.WORD
Active:
Immediately
The number of control output filters must be set in this machine data.
Table 4-6 Selecting the number of control output filters
0 No filter(s) active (default)
1 Filter(s) activated
Note
The filter machine data must be assigned before the filter type is configured.
5281
OUTPUT_FILTER_TYPE [n] 0...7 index of the parameter set
Cross reference: -
Type of control output filter Related to:
HLA
Protection level:
3/3
Unit:
-
Default:
0
Minimum:
0
Maximum:
1
Data type:
UNS.WORD
Active:
Immediately
The type of control output filter is entered in this machine data.
Table 4-7 Type of control output filter
Bit 0
0 Low-pass (see MD 5284/5285)
Bit 0
1 Bandstop filter (refer to MD 5288/5289/5290)
5284
OUTPUT_FIL_1_FREQ [n] 0...7 index of the parameter set
Cross reference: -
Natural frequency of control output filter 1 Related to:
HLA
Protection level:
3/3
Unit:
Hz
Default:
1000.0
Minimum:
10.0
Maximum:
8000.0
Data type:
FLOAT
Active:
Immediately
The filter key data is defined in MD 5284, MD 5285 and MD 5288 to MD 5290.
Enter the natural frequency for control output filter 1 (PT2 low-pass). Setting a
value of <10 Hz for the natural frequency of the low pass initializes the filter as a
proportional element with a gain of 1, irrespective of the associated damping.
4 Firmware Drive Functions
