10.03
5.1 Interface overview
5-180
Siemens AG, 2003. All rights reserved
SINUMERIK 840D/SIMODRIVE 611 digital, HLA Module (FBHLA) - 10.03 Edition
5.1.3 Servo solenoid valve
S X121: Axis 1
S X122: Axis 2
Table 5-3 Connectors X121, X122; both are 15-pin subminiature D female
connectors
Pin X121 X122 Function
1 P24RV1 P24RV2 +24 V switched
2 P24RV1 P24RV2 +24 V switched
3 P24RV1 P24RV2 +24 V switched
4 P24RV1 P24RV2 +24 V switched
5 M (GND) M (GND) Functional ground
6 USOLL1N USOLL2N Analog setpoint output, reference ground
7 USOLL1P USOLL2P Analog setpoint output +/-10 V
8 M (GND) M (GND) Functional ground
9 M24EXT M24EXT 24 V external ground
10 M24EXT M24EXT 24 V external ground
11 M24EXT M24EXT 24 V external ground
12 - - Not assigned
13 M (GND) M (GND) Functional ground
14 UIST1N UIST2N Analog valve actual-value input, reference ground
15 UIST1P UIST2P Analog valve actual-value input, +/-10 V
The analog valve actual value inputs are differential with 100 kΩ input
resistance.
The current ratings of the 24 V outputs on the servo solenoid value are
S for an ambient temperature of 40 °C 2.0 A
S for an ambient temperature of 55 °C 1.5 A
for the mean current value with a load cycle of 10 s duration.
The temperature corner points may be interpolated linearly.
The short-term current rating of the servo solenoid valve outputs is 3.0 A
(200 ms).
In the event of overload, fuse F1900 or F1901 on the HLA closed-loop control
plug-in module (for position, see Fig. 5-2) will blow.
The switched 24 V outputs for axes 1 and 2 are protected by miniature fuses;
fuse type F1900 for axis 1 and F1901 for axis 2.
Value: 2.5 AF/250 V; 5x20 mm UL
From: Wickmann-W erke GmbH
Annenstraße 113
58453 Witten
or
PO Box 2520
58415 Witten
Order No.: 194
Fuse
5 Hardware Drive Functions
