10.03
4.15 Parameters table
4-165
Siemens AG, 2003. All rights reserved
SINUMERIK 840D/SIMODRIVE 611 digital, HLA Module (FBHLA) - 10.03 Edition
5735 PROCESSOR_UTILIZATION Cross reference: -
Processor capacity utilization Related to:
HLA
Protection level:
3/3
Unit:
%
Default:
0
Minimum:
0
Maximum:
FFFF
Data type:
UNS. WORD
Active:
Read-only
The processor capacity utilization display provides online information about
available computing capacity.
4.15 Parameters table
The machine data is preset to this value during start-up.
Specifies the input limits. If no range of values is specified, the data type deter-
mines the input limits and the field is marked “∗∗∗”.
S POWER ON (po) “RESET” key on front panel of NCU module
or disconnection and reconnection of power supply
or “NCK reset” soft key
S NEW_CONF (cf) - “Set MD active” soft key on HMI
- “RESET” key on control unit,
- Changes at block ends possible in program mode
S RESET at end of program M2/M30
S RESET (re) “RESET” key on control unit or
S Immediately (im) after entry of the value
The levels of effectiveness have been listed above in order of priority.
Protection levels 0 to 7 have been used. The lock for protection levels 0 to 3
(4 to 7) can be canceled by entering the correct password (correct keyswitch
position). The operator only has access to information protected by one particu-
lar level and the levels below it.
Meanings of numbers
0 or 10: SIEMENS
1 or 11: OEM-HIGH
2 or 12: OEM-LOW
3 or 13: End user
4 or 14: Keyswitch position 3
5 or 15: Keyswitch position 2
6 or 16: Keyswitch position 1
7 or 17: Keyswitch position 0
Processor capacity
utilization
Default value
Range of values
(minimum and
maximum)
Changes take
effect
Protection level
4 Firmware Drive Functions
02.99
