7.2 BERO (X432)
7-226
 Siemens AG, 2003. All rights reserved
SINUMERIK 840D/SIMODRIVE 611 digital, HLA Module (FBHLA) - 10.03 Edition
7.2 BERO (X432)
Only BEROs of type 3-wire PNP NO contact may be used.
We recommend the following BERO models:
SIEMENS BERO M30 3RG 4014-0AG01
BERO M12 3RG 4012-3AG01
Note
The BERO cable must be shielded.
Table 7-2 Pin assignment X432
Terminal name Type
1)
Signal designation
B1/B2 I BERO (external reference system) axis 1/2
19 O Power supply for BERO ground external
9 O Power supply for BERO 24 V external
1) I: Input, O: Output
7 Peripherals/Accessories
02.99

Siemens Sinumerik 840D Series Specifications

General

Axes	Up to 31 axes
Power Supply	24 V DC
Control Type	CNC
Interface	Ethernet, PROFIBUS
Display	TFT color display
PLC	Integrated PLC (programmable logic controller)
Operating Temperature	0°C to 45°C
Relative Humidity	Up to 95% (non-condensing)
Max. Number of Channels	Up to 10 channels
