10.03
4.14 Service functions
4-161
 Siemens AG, 2003. All rights reserved
SINUMERIK 840D/SIMODRIVE 611 digital, HLA Module (FBHLA) - 10.03 Edition
4.14.3 Diagnostic machine data
Various machine data is provided in the HLA module for diagnostic purposes.
NC diagnostic displays are available in a similar way to those used on electrical
drives.
5700 TERMINAL_STATE Cross reference: -
Status of binary inputs
Bit 0: 26.5 V supply available
Bit 1: Term. 663 available
Bit 2: Term. 63 available
Bit 3: HW enable aggregate signal set
Bit 5: Setup mode selected
Bit 6: Term. 64 available
Bit 12: 24 V servo solenoid valve ON
Bit 13: 24 V shutoff valve ON
Related to:
HLA
Protection level:
3/3
Unit:
HEX
Default:
0
Minimum:
0
Maximum:
FFFF
Data type:
UNS.WORD
Active:
Immediately
5704 ACTUAL_PRESSURE_A Cross reference: -
Actual pressure A Related to:
HLA
Protection level:
3/3
Unit:
bar
Default:
0.0
Minimum:
-10000.0
Maximum:
10000.0
Data type:
FLOAT
Active:
Immediately
5705 ACTUAL_PRESSURE_B Cross reference: -
Actual pressure B Related to:
HLA
Protection level:
3/3
Unit:
bar
Default:
0.0
Minimum:
-10000.0
Maximum:
10000.0
Data type:
FLOAT
Active:
Immediately
5706 DESIRED_SPEED Cross reference: -
Velocity setpoint Related to:
HLA
Protection level:
3/3
Unit:
mm/min
Default:
0.0
Minimum:
-240000.0
Maximum:
240000.0
Data type:
FLOAT
Active:
Immediately
5707 ACTUAL_SPEED Cross reference: -
Actual velocity value Related to:
HLA
Protection level:
3/3
Unit:
mm/min
Default:
0.0
Minimum:
-240000.0
Maximum:
240000.0
Data type:
FLOAT
Active:
Immediately
5709 VOLTAGE_LSB Cross reference: -
Significance of voltage representation
Defines how many volts [V] correspond to 1 increment
of the internal voltage format (valve spool setpoint/actual
value).
Related to:
HLA
Protection level:
3/3
Unit:
V
Default:
0.0
Minimum:
-100000.0
Maximum:
100000.0
Data type:
FLOAT
Active:
Immediately
5710 PRESSURE_LSB Cross reference: -
Significance of pressure representation
Defines the pressure in [bar] corresponding to 1
increment of the internal pressure format.
Related to:
HLA
Protection level:
3/3
Unit:
bar
Default:
0.0
Minimum:
-240000.0
Maximum:
240000.0
Data type:
FLOAT
Active:
Immediately
4 Firmware Drive Functions
02.99
