Siemens Sinumerik 840D Series Function Manual

10.03
4.14 Service functions
4-162
 Siemens AG, 2003. All rights reserved
SINUMERIK 840D/SIMODRIVE 611 digital, HLA Module (FBHLA) - 10.03 Edition
5711 SPEED_LSB Cross reference: -
Significance of velocity representation
Defines the velocity in [mm/min] corresponding to
1 increment of the internal velocity format.
Related to:
HLA
Protection level:
3/3
Unit:
mm/min
Default:
0.0
Minimum:
-240000.0
Maximum:
240000.0
Data type:
FLOAT
Active:
Immediately
5713 FORCE_LSB Cross reference: -
Significance of force representation
Defines the force in [µN] corresponding to
1 increment of the internal force format.
Related to:
HLA
Protection level:
3/3
Unit:
µN
Default:
0.0
Minimum:
-10000000.0
Maximum:
10000000.0
Data type:
FLOAT
Active:
Immediately
5714 POSITION_LSB Cross reference: -
Significance of position representation
Defines the position in [nm] corresponding
to 1 increment of the internal position format.
Related to:
HLA
Protection level:
3/3
Unit:
nm
Default:
0.0
Minimum:
-1000000.0
Maximum:
1000000.0
Data type:
FLOAT
Active:
Immediately
5715 DESIRED_VALVE_SPOOL_POS Cross reference: -
Voltage for valve spool position setpoint Related to:
HLA
Protection level:
3/3
Unit:
V
Default:
0.0
Minimum:
-10.0
Maximum:
10.0
Data type:
FLOAT
Active:
Immediately
5716 ACTUAL_VALVE_SPOOL_POS Cross reference: -
Voltage for actual valve spool position value Related to:
HLA
Protection level:
3/3
Unit:
V
Default:
0.0
Minimum:
-10.0
Maximum:
10.0
Data type:
FLOAT
Active:
Immediately
5725 MAX_FORCE_FROM_NC Cross reference: -
Normalization of force setpoint interface
in high-speed PLC data channel.
4000hex corresponds to value in MD 5725.
Related to:
HLA
Protection level:
3/3
Unit:
N
Default:
0.0
Minimum:
0.0
Maximum:
10000000.0
Data type:
FLOAT
Active:
Immediately
The value in MD 5725 equals 100% of the set value from the NC program
(FXST[X]=100).
5740 ACTUAL_POSITION Cross reference: -
Actual position in relation to machine zero Related to:
HLA
Protection level:
3/3
Unit:
mm
Default:
0.0
Minimum:
-10000000.0
Maximum:
10000000.0
Data type:
FLOAT
Active:
Immediately
5741 ACTUAL_PISTON_POSITION Cross reference: -
Piston position in relation to piston zero Related to:
HLA
Protection level:
3/3
Unit:
mm
Default:
0.0
Minimum:
-10000000.0
Maximum:
10000000.0
Data type:
FLOAT
Active:
Immediately
4 Firmware Drive Functions

Siemens Sinumerik 840D Series Specifications

General

Axes	Up to 31 axes
Power Supply	24 V DC
Control Type	CNC
Interface	Ethernet, PROFIBUS
Display	TFT color display
PLC	Integrated PLC (programmable logic controller)
Operating Temperature	0°C to 45°C
Relative Humidity	Up to 95% (non-condensing)
Max. Number of Channels	Up to 10 channels
