7.3.2 Connection diagrams
Note
The following cable data for hydraulic systems is tailored specifically to Bosch
Rexroth products. If hydraulics components supplied by other manufacturers
are used, the pin assignments of the hydraulic-end connections might be
different!
PIST1AN
Length according to length code
2
3
1
Sub D male connector, 15-pin, with screw lock UNC 4-40
6FC9341-1HC
0,18
0,18
0,18
0,18
bk
bn
bn
rd
rd
or
or
P24DS
P24DS
PIST1AP
PIST1BP
2
2
1
1
3
3
4
4
Housing
Uext. 0 V
Uext. 0 V
Uext. 24 V
Uext. 24 V
Actual value, 0...10 V
Actual value, 0...10 V
Actual value, ground
Actual value, ground
HLA module
2
1
15
12
14
11
Item Meaning
Male connector
S 4-pin socket included with pressure sensor
Bosch Rexroth order no.: 1 834 484 061 or 1 834 484 063
S 7-pin socket not included with pressure sensor
Bosch Rexroth order no.: 1 834 484 141
Signal lead 2x(2x0.18) C
6FX2008-1BD71
1
2
3
5
9
Order No. (MLFB) of signal lead for pressure sensors: 6FX2002-2AD00-1 VVV
Pin 1
Cable print (order no., length in m, manufacturer,
month/year of manufacture)
M24EXT
M24EXT
Shield
Shield
O
B
O
B
1)
1)
PIST1BN
0,18
0,18
0,18
0,18
bk
Pressure sensor A or B
1) Shield insulated
Note: Max. approved system cable length 40 m
3
3
Fig. 7-10 Signal lead for pressure sensors (X111/X112)
