10.03
4.14 Service functions
4-160
Siemens AG, 2003. All rights reserved
SINUMERIK 840D/SIMODRIVE 611 digital, HLA Module (FBHLA) - 10.03 Edition
5653 MINMAX_MIN_VALUE Cross reference: -
Minimum value of min/max memory Related to:
HLA
Protection level:
3/3
Unit:
HEX
Default:
0
Minimum:
0
Maximum:
FFFFFF
Data type:
UNS.DWORD
Active:
Immediately
5654 MINMAX_MAX_VALUE Cross reference: -
Maximum value of min/max memory Related to:
HLA
Protection level:
3/3
Unit:
HEX
Default:
0
Minimum:
0
Maximum:
FFFFFF
Data type:
UNS.DWORD
Active:
Immediately
4.14.2 Monitor
Note
Machine data MD 5655 to MD 5659 are relevant only for internal Siemens
functions and must not be changed.
5655 MONITOR_SEGMENT Cross reference: -
Monitor memory location segment Related to:
HLA
Protection level:
3/3
Unit:
HEX
Default:
0
Minimum:
0
Maximum:
FFFF
Data type:
UNS.WORD
Active:
Immediately
5656 MONITOR_ADDRESS Cross reference: -
Monitor memory location address Related to:
HLA
Protection level:
3/3
Unit:
HEX
Default:
0
Minimum:
0
Maximum:
FFFFFF
Data type:
UNS.DWORD
Active:
Immediately
5657 MONITOR_DISPLAY Cross reference: -
Monitor value display Related to:
HLA
Protection level:
3/3
Unit:
HEX
Default:
0
Minimum:
0
Maximum:
FFFFFF
Data type:
UNS.DWORD
Active:
Immediately
5658 MONITOR_INPUT_VALUE Cross reference: -
Monitor value input Related to:
HLA
Protection level:
3/3
Unit:
HEX
Default:
0
Minimum:
0
Maximum:
FFFFFF
Data type:
UNS.DWORD
Active:
Immediately
5659 MONITOR_INPUT_STROBE Cross reference: -
Monitor value transfer Related to:
HLA
Protection level:
3/3
Unit:
HEX
Default:
0
Minimum:
0
Maximum:
FFFF
Data type:
UNS.WORD
Active:
Immediately
4 Firmware Drive Functions
