Siemens Sinumerik 840D Series Function Manual

10.03
7.1 Measuring systems
7-222
 Siemens AG, 2003. All rights reserved
SINUMERIK 840D/SIMODRIVE 611 digital, HLA Module (FBHLA) - 10.03 Edition
7.1.2 Connection diagrams
Hydraulics
module
(HLA)
X101/X102
6FX2002 - 2CA11 - 1jjj
v 40 m
Incremental
encoder 1 Vpp
6FX2002 - 2AD00 - 1jjj
v 40 m
Linear
absolute
measuring system
(EnDat) LC 181
Adapter cable
1)
313 791
Adapter cable
1)
310 128
310 123
6FX8002 - 2CC80 - 1jjj
v 40 m
Linear
absolute
measuring system
SSI
Adapter cable
1)
Direct linear
incremental
measuring system
LS 186
LS 486
Fig. 7-3 Example showing connection options for measuring system cable
1) Adapter cable can be ordered from supplier of linear scale.
MTS: Order code 252 882
Balluff: BKS-S 32M/SA1-jj
Visolux: ASK EDM-SSI-SIMODRIVE
Connection
options
7 Peripherals/Accessories

Siemens Sinumerik 840D Series Specifications

General

Axes	Up to 31 axes
Power Supply	24 V DC
Control Type	CNC
Interface	Ethernet, PROFIBUS
Display	TFT color display
PLC	Integrated PLC (programmable logic controller)
Operating Temperature	0°C to 45°C
Relative Humidity	Up to 95% (non-condensing)
Max. Number of Channels	Up to 10 channels
