Siemens Sinumerik 840D Series Function Manual

10.03
4.13 Monitoring functions
4-152
 Siemens AG, 2003. All rights reserved
SINUMERIK 840D/SIMODRIVE 611 digital, HLA Module (FBHLA) - 10.03 Edition
4.13 Monitoring functions
4.13.1 Alarms
5600 ALARM_MASK_POWER_ON Cross reference: -
Concealable alarms (Power On)
Bit 4: “Measuring circuit measuring system”
Bit 5: Measuring circuit absolute track (incl. SSI encoder)
Bit 8: “Zero marker error”
Related to:
HLA
Protection level:
3/3
Unit:
HEX
Default:
0
Minimum:
0
Maximum:
FFFF
Data type:
UNS.WORD
Active:
Immediately
5612 ALARM_REACTION_POWER_ON Cross reference: -
Config. shutdown response to PO alarms
Bit 0= 0: No enable signal cancellation in response to
internal errors
1: Enable signal cancellation in response to internal
errors
Related to:
HLA
Protection level:
3/3
Unit:
HEX
Default:
0
Minimum:
0
Maximum:
FFFF
Data type:
UNS.WORD
Active:
Immediately
5731 CL1_PO_IMAGE Cross reference: -
Image ZK1_PO register Related to:
HLA
Protection level:
3/3
Unit:
HEX
Default:
0
Minimum:
0
Maximum:
FFFF
Data type:
UNS.WORD
Active:
Immediately
With MD 5600: ALARM_MASK_POWER_ON can be set to conceal Power On
alarms. If the relevant bit is set to 0, the corresponding error monitoring function
is active. If the bit=1, the error monitoring function is suppressed. The default
setting is active for all monitoring functions.
With MD 5612: ALARM_REACTION_POWER_ON is set to configure change-
over of the relevant Power On alarm.
Alarm messages, see Chapter 6, numbers 300500...300599.
5601 ALARM_MASK_RESET Cross reference: -
Concealable alarms (Reset)
Bit 7: “Valve controller not responding”
Bit 8: “Velocity controller at limit”
Bit 9: “Encoder limit frequency exceeded”
Bit 10: “Piston position negative”
Bit 11: “Pressure sensing failed”
Bit 12: “Force limitation OFF”
Bit 13: “External valve voltage supply check Off”
(“26.5 V monitoring””
Related to:
HLA
Protection level:
3/3
Unit:
HEX
Default:
0
Minimum:
0
Maximum:
FFFF
Data type:
UNS.WORD
Active:
Immediately
Power On alarms
RESET alarms
4 Firmware Drive Functions
