10.03
5.3 Notes
5-186
Siemens AG, 2003. All rights reserved
SINUMERIK 840D/SIMODRIVE 611 digital, HLA Module (FBHLA) - 10.03 Edition
5.3.2 Transport and storage conditions
Note
The following information refers to the electrical section of the HLA.
IEC 68-2-1, IEC 68-2-2, IEC 68-2-3
The following data applies to modules in their original packaging:
Table 5-8 Climatic conditions
Temperature range Lower limit temperature -40 °C
Upper limit temperature +70°C
Dew-point temperature td
and relative air humidity U
Annual average U = 75%, td = 17°C
On 30 days (24 hours) in
year (days distributed over
the annual period)
U = 95%, td = 24°C
On 30 days (24 hours) in
year (days distributed over
the annual period)
U = 85%, td = 20°C
Condensation
As regards condensation,
the following conditions may
apply simultaneously:
Seldom, brief, slight
Max. condensation period 3 hours
Frequency of condensation Annual average 3/Max.: 10
Shortest sequence of con-
densation cycles
1 day
Temperature rate of
change
Within one hour 20 K
Air pressure The specified values apply
to a transportation altitude
of up to 3265 m above sea
level
66 kPa to 108 kPa
Table 5-9 Mechanical conditions during transportation in original packaging
Vibration resistance (to
IEC 68-2-6)
Frequency range
5 - 9 Hz
Over 9 - 500 Hz
Const. Deflection
3.5 mm
Ampl. of acceleration
10 m/s
2
Relevant
standards
Originally
packaged modules
5 Hardware Drive Functions
02.99
