10.03
4.14 Service functions
4-164
Siemens AG, 2003. All rights reserved
SINUMERIK 840D/SIMODRIVE 611 digital, HLA Module (FBHLA) - 10.03 Edition
If the force controller (force limitation or friction injection) has been activated in
MD 5241, the effective force setpoint is displayed here. This can be specified
by:
S the force limitation (MD 5230 or 5231)
S the friction injection (MD 5234 or MD 5235)
S the NC via the “Travel to fixed stop” function
It must be noted that the force controller is activated only in conjunction with
friction injection and zero speed or with force limitation and violation of the upper
force limit. The voltage setpoint of the velocity controller is otherwise applied, in
which case the force setpoint is irrelevant.
5797 PBL_VERSION Cross reference: -
Data version Related to:
HLA
Protection level:
3/3
Unit:
-
Default:
0
Minimum:
0
Maximum:
FFFF
Data type:
UNS.WORD
Active:
Immediately
Output of current data version (machine data list).
5798 FIRMWARE_DATE Cross reference: -
Firmware date Related to:
HLA
Protection level:
3/3
Unit:
-
Default:
0
Minimum:
0
Maximum:
FFFF
Data type:
UNS.WORD
Active:
Immediately
Output of coded software release. The display is decimal. The character string
has the following format:
DDMMY, in which DD stands for day, MM for month and Y = last digit of year.
Example: The code for 01.06.1993 is 1063
dec
5799 FIRMWARE_VERSION Cross reference: -
Firmware version Related to:
HLA
Protection level:
Unit:
-
Default:
0
Minimum:
0
Maximum:
FFFFFF
Data type:
UNS.DWORD
Active:
Read-only
Output of current software release. The display is decimal, e.g. 21000. This is
the code for SW version 2.10/00.
Software version
