Siemens Sinumerik 840D Series Function Manual

10.03
7.3 Pressure sensor
7-228
 Siemens AG, 2003. All rights reserved
SINUMERIK 840D/SIMODRIVE 611 digital, HLA Module (FBHLA) - 10.03 Edition
Table 7-3 Recommended types of pressure sensor
Signal Pressure range Male connector Rexroth order no.
0...10 V 100 bar Rectangular connector,
4-pin
0811 405 554
210 bar
4-pin
0811 405 540
350 bar 0811 405 547
210 bar 7-pin circular connector 0811 405 531
350 bar 0811 405 532
15
"
1
Tightening torque 0.3 - 0.4 Nm
71.5
-2
12
"
1
22.5
O 35
O 18.8
G1/4”ISO 228 A
O-ring 13x2
Conduit thread 7
SW 32
=20
+5
Nm
Ref. 0 V (signal)
U
sig
0 V
Supply
4
3
2
1
P
U
41
32
Bosch Rexroth
11
"
1
45
"
1
Fig. 7-7 Rexroth pressure sensors, order nos. 0811 405 540, 0811 405 547 and 0811 405 554
Dimensions/termin
al assignments
7 Peripherals/Accessories

Siemens Sinumerik 840D Series Specifications

General

Axes	Up to 31 axes
Power Supply	24 V DC
Control Type	CNC
Interface	Ethernet, PROFIBUS
Display	TFT color display
PLC	Integrated PLC (programmable logic controller)
Operating Temperature	0°C to 45°C
Relative Humidity	Up to 95% (non-condensing)
Max. Number of Channels	Up to 10 channels
