Siemens SINUMERIK 840D sl Commissioning Manual

Commissioning the system
1.2 User administration
PCU-Basesoftware (IM8)
14 Commissioning Manual, 02/2014, 6FC5397-1DP40-4BA0
"Startup (1)" tab
Figure 1-3 Global Settings: Startup (1) tab
Table 1- 1 The default is marked in "
bold
".
Startup (1) tab
Option
Effect
Background
Bitmaps folder: F:\hmisl\siemens\sinumerik
\hmi\ico\ ...
Directory with boot screens
Default bitmap folder:
F:\hmisl\siemens\sinumerik
\hmi\ico\ico800
Directory containing default boot screens
Installing
Enable:
"yes"
Authorization is in place to install user
software during booting.
"no"
No installation authorization
Logon dialog:
"yes"
Display "Installing Logon" dialog.
"no"
Do not display "Installing Logon" dialog.
Veto Dialog:
"no"
For pending installation during the boot up:
No prompting, the installation begins
immediately.

Siemens SINUMERIK 840D sl Specifications

General

Control Type	CNC
Number of Axes	Up to 31
Max Number of Channels	10
Interfaces	Ethernet, PROFIBUS, PROFINET, USB
Interpolation	5-axis interpolation
Operating Temperature	0°C to 45°C
Relative Humidity	Up to 95% (non-condensing)
Display	TFT color display, various sizes
Programming Languages	DIN/ISO
Safety Features	Safety Integrated
PLC	Integrated PLC S7-300
Drive Interface	SINAMICS S120
Data Storage	CF card, USB
Operating System	Windows-based
