Siemens SINUMERIK 840D sl Commissioning Manual

Commissioning the system
1.2 User administration
PCU-Basesoftware (IM8)
Commissioning Manual, 02/2014, 6FC5397-1DP40-4BA0
15
Startup (1) tab
Option
Effect
"yes" For pending installation during the boot up:
Prompt asking whether to install.
Authentication:
"manual"
Authentication of an HMI+Service user in
the "Installing Logon" dialog is undertaken
manually.
"EKS" Authentication of an HMI+Service user in
the "Installing Logon" dialog involves EKS.
The "Installing Logon" dialog appears if
authentication by EKS has failed in the
background.
"manual+EKS" Authentication of an HMI+Service user in
the "Installing Logon" dialog either involves
EKS or is performed manually.

Siemens SINUMERIK 840D sl Specifications

General

Control Type	CNC
Number of Axes	Up to 31
Max Number of Channels	10
Interfaces	Ethernet, PROFIBUS, PROFINET, USB
Interpolation	5-axis interpolation
Operating Temperature	0°C to 45°C
Relative Humidity	Up to 95% (non-condensing)
Display	TFT color display, various sizes
Programming Languages	DIN/ISO
Safety Features	Safety Integrated
PLC	Integrated PLC S7-300
Drive Interface	SINAMICS S120
Data Storage	CF card, USB
Operating System	Windows-based
