Siemens SINUMERIK 840D sl Commissioning Manual

Commissioning the system
1.2 User administration
PCU-Basesoftware (IM8)
16 Commissioning Manual, 02/2014, 6FC5397-1DP40-4BA0
"Startup (2)" tab
Figure 1-4 "Startup (2)" tab
Table 1- 2 The default is marked in "
bold
".
Startup (2) tab
Option
Effect
Keys, filtering
Enable
"yes"
Key filtering is activated.
"no"
Key filtering not activated.
Filter file
E:\WINDOWS\System.ini
Select the file with filter settings
Desktop Logon
Start dialog:
"yes"
Display "Desktop Access" dialog
"no"
Do not display "Desktop Access" dialog
Logon Dialog:
"yes"
Display "Desktop Logon" dialog.
"no"
Do not display "Desktop Logon" dialog.
Default password map:
"no"
The password must be entered exactly as
specified.
"yes"
The password is not case-sensitive.
Authentication:
"manual"
Authentication with user name and
password (manual)
"EKS"
Authentication with EKS
"manual+EKS" Either authentication with user name and
password or with EKS

Siemens SINUMERIK 840D sl Specifications

General

Control Type	CNC
Number of Axes	Up to 31
Max Number of Channels	10
Interfaces	Ethernet, PROFIBUS, PROFINET, USB
Interpolation	5-axis interpolation
Operating Temperature	0°C to 45°C
Relative Humidity	Up to 95% (non-condensing)
Display	TFT color display, various sizes
Programming Languages	DIN/ISO
Safety Features	Safety Integrated
PLC	Integrated PLC S7-300
Drive Interface	SINAMICS S120
Data Storage	CF card, USB
Operating System	Windows-based
